CVHE-SVX02M-EN

Table 5. Weights, 50 Hz chillers (kg) (continued)

Model

Comp Size

CPKW

Evap Size

Cond Size

Weights without Starters Weights with Starters

NTON EVSZ CDSZ

Operating Shipping Operating Shipping

480–565 489 050S 080S 11736 10223 11989 10476

480–565 489 050L 080L 13024 11180 13276 11432

480–565 489 080S 080L 15095 13043 15348 13295

670–780 621 080S 080S 14947 13033 15199 13285

670–780 621 080S 080L 15667 13615 15920 13867

670–780 621 080L 080L 16584 14257 16836 14510

670–780 621 080L 142L 20421 17329 20673 17581

670–780 621 142M 142L 22461 18852 22714 19105

670–780 621 142L 142L 23038 19266 23290 19519

920–1100 621 080L 142L 20904 17812 21157 18065

920–1100 892 142M 142L 23128 19519 23380 19772

920–1100 892 142L 142L 23704 19933 23957 20186

920–1100 892 142M 210L 25848 21718 26100 21970

920–1100 892 142L 210L 26401 22132 26654 22384

920–1100 892 142E 210L 27048 22579 27300 22832

920–1100 892 210L 210L 28949 24381 29201 24634

These representative chiller weight values are based on the following:

Notes:

1. TECU tubes, 0.71 mm tube wall thickness.

2. 2068.4 kPaG non-marine waterboxes.

3. Heaviest possible bundle and motor combination.

4. Operating weights assume the largest possible refrigerant charge.

5. Weights with starters assume the heaviest possible starter (AFD when it’s an allowed option).

6. Industrial Control Panel (INDP) option, add 23 kg.

7. Control Power Transformer (CPTR) option, add 59 kg.

8. Supplemental Motor Protection (SMP) option, add 227 kg.

UUnniitt CClleeaarraanncceess aanndd WWeeiigghhttss
