26 Direct-Fired Make-up Air • MUA-SVX01A-EN
Rigging/ Suspension
Note 7. Right hand shown, left hand opposite.
Note 8. Unit configuration shown may not match specific configuration. Lifting points shown are typical per section
(section order is not relevant).
Figure 7. Vibration Feet Assembly (typical for indoor units)
Size A
109-118 6"
120-230 4 1/2"
Figure 8. Plan View
Denotes typical vibration mounts
