Electrical Data
WSHP-SVX01Q-EN 85
GEV180 230/60/3 63.2 25 164 2 39 13.2 5.0 1 69.45 90
GEV180 460/60/3 31.0 12.2 100 2 19 6.6 5.0 1 34.05 45
GEV180 208/60/3 72.1 25 164 2 39 22.1 7.5 1 78.35 100
GEV180 230/60/3 70.0 25 164 2 39 20.0 7.5 1 76.25 100
GEV180 460/60/3 34.4 12.2 100 2 19 10.0 7.5 1 37.45 45
GEV240 208/60/3 74.8 30.1 225 2 47 14.6 5.0 1 82.33 110
GEV240 230/60/3 73.4 30.1 225 2 47 13.2 5.0 1 80.93 110
GEV240 460/60/3 40.0 16.7 114 2 26 6.6 5.0 1 44.18 60
GEV240 208/60/3 82.3 30.1 225 2 47 22.1 7.5 1 89.83 110
GEV240 230/60/3 80.2 30.1 225 2 47 20.0 7.5 1 87.73 110
GEV240 460/60/3 43.4 16.7 114 2 26 10.0 7.5 1 47.58 60
GEV240 208/60/3 87.8 30.1 225 2 47 27.6 10.0 1 95.33 125
GEV240 230/60/3 85.2 30.1 225 2 47 25.0 10.0 1 92.73 110
GEV240 460/60/3 46.4 16.7 114 2 26 13.0 10.0 1 50.58 60
GEV240 460/60/3 53.4 16.7 114 2 26 20.0 15.0 1 58.40 70
GEV300 208/60/3 110.8 48.1 245 2 75 14.6 5.0 1 122.83 150
GEV300 230/60/3 109.4 48.1 245 2 75 13.2 5.0 1 121.43 150
GEV300 460/60/3 43.8 18.6 125 2 29 6.6 5.0 1 48.45 60
GEV300 208/60/3 118.3 48.1 245 2 75 22.1 7.5 1 130.33 175
GEV300 230/60/3 116.2 48.1 245 2 75 20.0 7.5 1 128.23 175
GEV300 460/60/3 47.2 18.6 125 2 29 10.0 7.5 1 51.85 70
GEV300 208/60/3 123.8 48.1 245 2 75 27.6 10.0 1 135.83 175
GEV300 230/60/3 121.2 48.1 245 2 75 25.0 10.0 1 133.23 175
GEV300 460/60/3 50.2 18.6 125 2 29 13.0 10.0 1 54.85 70
GEV300 460/60/3 57.2 18.6 125 2 29 20.0 15.0 1 62.20 80
Table 50. Electrical data two speed blower motor 6 to 25 tons (continued)
Model
No. Volts
Total
FLA
Comp RLA
(ea)
Comp
LRA
(ea)
No. of
Comp. Cmp MCC
Blower
Motor
FLA
Blower
Motor
HP
Fan
Motor
No.
Minimum
Circuit
Ampacity
Maximum
Overcurrent
Protective
Device
Table 51. Electrical minimum and maximum .5 to 25 tons
Digit 8 Rated Voltage Hz Ph Min Utiliz. Volts Max Utiliz. Volts
0 115 60 1 104 126
1 208 60 1 197 229
2 230 60 1 207 253
3 208 60 3 187 229
4 460 60 3 414 506
5 575 60 3 518 633
7 265 60 1 239 292
8 230 60 3 207 253
