Table 3. Parts list
Item Description Qty
- Outside air damper assembly 1
Hood parts (Carton A):
1 Right hood panel 1
2 Left hood panel 1
3 Filter side angle bracket 2
4 Filter rear angle bracket 1
5 Hood front support bracket 1
6 Filter top support bracket 1
7 Economizer diverter panel 1
8 Filter 1
9
Hardware bag:
• 52 Type AB sheet metal screws with sealing washer (#10-16 x 5/8 in.)
• Identification label
• Installation instructions
1
Field only parts (Carton B):
(a)
(a) These parts are already installed in the factory installed option.
10 Outside air block-off 1
11 Return air block-off, back subassembly 1
12 Return air block-off, front subassembly 1
13 Controls harness 1
Field supplied part:
- Tube sealant - Trane recommends Sikaflex 221 (SEL00439) -
General Information - FIAECON103*
10 ACC-SVN264B-EN
