Upon powering the unit, the Symbio 700 performs self
diagnostic checks to verify all internal controls are
functional. When the user interface is ready or the mobile
app is connected to the Symbio 700 controls, use the
following test procedure to start the unit at the control
panel. Each test step can be activated individually by
selecting the unit operating stage desired. The unit can be
left in any test step for up to one hour (adjustable to values
between 1 and 120 minutes) before Service Test will
automatically terminate. Once Service Test has been
terminated, a system reset will occur and the unit will revert
to the normal system control.
Table 10. Service test state request
Device Request /
Service Test Step
(a)
Supply fan
On/Off
request
Supply fan
speed request
(VVZT, CVZT)
Outdoor air
damper
position
request
Compressor
cool stage
request
Condenser
Fan (Info
Only)
(b)
Aux heat
stage request
Relief fan On/
Off request
Heat cool
mode status
(VVZT, CVZT)
Inactive In Control In Control In Control In Control In Control In Control In Control In Control
Fan On ON Min Min 0 In Control 0 In Control Test
Fan On Econ Open
ON Min 100 0 In Control 0 In Control Test
High Fan Speed Econ
Open
ON 100 100 0 In Control 0 In Control Test
Ventilation Low Fan Speed
ON Min
Design Min
0 In Control 0
Ventilation Mid Fan Speed
ON
Effective Mid
(c)
Design Mid
0 In Control 0 In Control Test
Ventilation High Fan Speed
ON 100
Design Max
0 In Control 0 In Control Test
Cool 1 ON
Min for Capacity
Min 1 In Control 0 In Control Test
Cool 2 ON
Min for Capacity
Min 2 In Control 0 In Control Test
Cool 3 ON
Min for Capacity
Min 3 In Control 0 In Control Test
Cool 4 ON
Min for Capacity
Min 4 In Control 0 In Control Test
Cool 5 ON
Min for Capacity
Min 5 In Control 0 In Control Test
Heat 1 ON 100 Min 0 In Control 1 In Control Test
Heat 2 ON 100 Min 0 In Control 2 In Control Test
(a)
Service test mode is allowed to perform Dx cooling and heating operation regardless of the Refrigerant Mitigation Active status.
(b)
Condenser fan is always in control during active service test mode.
(c)
Supply Fan Speed Request "Effective Mid" equals to ( Effective Maximum Fan Speed + Effective Minimum Fan Speed )/2.
