Trane Foundation GBC090 User Manual

10
RT-SVX069A-EN
Figure 2. Gas/electric units — overview
GAS CONNECTION
DISCONNECT SWITCH ACCESS
Figure 3. Gas/electric units — front and side views
C
D
E
F
2 9/16”
Ø1 15/16”
Ø7/8”
Ø1 3/8”
Ø1 3/8”
Ø1 15/16”
2 3/8”
2 3/8”
Ø1 15/16”
NOTES:
1.THROUGH THE BASE GAS AND ELECTRICAL IS NOT STANDARD ON ALL UNITS.
2.VERIFY WEIGHT, CONNECTION, AND ALL DIMENSION WITH INSTALLER DOCUMENTS BEFORE INSTALLATION.
37 11/16”
29 3/8”
A
B
6 5/16”
88 1/4”
(GAC UNITS ONLY)
DDiimmeennssiioonnaall DDaattaa
