Trane Foundation GBC090 User Manual

RT-SVX069A-EN
11
Figure 4. Gas/electric units — plan view
88 1/4”
25 13/16”
14”
3 11/16”
29 3/8”
12 7/16”
27 1/4”
37 5/8”
40 11
/
1
6”
12 3/8”
36 7/16” 3 11/16”
SUPPLY
RETURN
THROUGH THE
BASE ELECTRICAL
NOTES:
1.THROUGH THE BASE GAS AND ELECTRICAL IS NOT STANDARD ON ALL UNITS.
3”
3”
2.VERIFY WEIGHT, CONNECTION, AND ALL DIMENSION WITH INSTALLER DOCUMENTS BEFORE INSTALLATION.
Figure 5. Foundation units — back view (horizontal configuration)
27 3/16”
52 7/16”
21 7/16”
12 3/8” 4 1/2”
RETURN
SUPPLY
13 7/8”
A
4 15/16”
5 3/4”
UNIT
DIMENSION
A
36 7/16”
34 13/16”
GBC090
GBC102
GBC120
GBC150
DDiimmeennssiioonnaall DDaattaa
