Trane GAM5A0C60M51SAA User Manual

32
STEP 8 - Replace Coil panel making sure that the
wires are located within the wire pass-through pro-
vided in the panel.
STEP 7 - Slide control plate assembly into the control
pocket until fully seated. The control plate should be
flush with the outer edge of the unit.
Pass through
notch in coil
access door

Trane GAM5A0C60M51SAA Specifications

General

Brand	Trane
Model	GAM5A0C60M51SAA
Category	Air Handlers
Language	English
