Trane HUV - Dimensional Data HUV-Bottom Double Deflection Discharge

108 UV-PRC001-EN
Dimensional Data
HUV-Bottom Double Deflection Discharge
Size A B C D
075 70 1/4" 36" 46" 43 1/4"
100 82 1/4" 48" 58" 55 1/4"
125 94 1/4" 60" 70" 67 1/4"
150 106 1/4" 72" 82" 79 1/4"
Unit Sizes 075-150
