Table 22: Weights & Measurements: Vertical Unit Ventilator
Unit Size 075 100 125 150
Unit Length w/o End Covers 69” 81” 93” 105”
Unit Height (Standard) 30” 30” 30” 30”
Unit Height (w/ 2” Subbase) 32” 32” 32” 32”
Unit Height (w/ 4” Subbase) 34” 34” 34” 34”
Unit Height (w/ 6” Subbase) 36” 36” 36” 36”
Unit Depth (Standard) 15 1/4” 15 1/4” 15 1/4” 15 1/4”
Unit Depth (1” Falseback) 16 1/4” 16 1/4” 16 1/4” 16 1/4”
Unit Depth (6” Falseback) 21 1/4” 21 1/4” 21 1/4” 21 1/4”
Shipping Weight (lbs.) 320 405 450 470
Filter Size (inches-actual) 41 1/2 x 13 3/8 x 1 53 1/2 x 13 3/8 x 1 65 1/2 x 13 3/8 x 1 77 1/2 x 13 3/8 x 1
Filter Size (dynamic-air) inches (2) 5 1/2 x 40 1/2 x 3/4 (2) 5 1/2 x 52 1/2 x 3/4 (2) 5 1/2 x 64 1/2 x 3/4 (2) 5 1/2 x 76 1/2 x 3/4
Table 23: Weights & Measurements: Horizontal Unit Ventilators
Unit Size 075 100 125 150 200
Unit Length 70 1/4” 82 1/4” 94 1/4” 106 1/4” 106 1/4”
Unit Height 16 5/8” 16 5/8” 16 5/8” 16 5/8” 17 5/8”
Unit Width (Front Discharge) 35 5/8” 35 5/8” 35 5/8” 35 5/8” 43 1/8”
Unit Width (Bottom Discharge) 48 3/4” 48 3/4” 48 3/4” 48 3/4” 57 1/4”
Shipping Weight (lbs.) * 340* 375* 435* 500* 600*
Filter Size (inches-actual)
41 1/2 x 15 1/4 x 1 53 1/2 x 15 1/4 x 1 65 1/2 x 15 1/4 x 1 77 1/2 x 15 1/4 x 1 77 1/2 x 15 1/4 x 1
*Working weight is approximately 10% less than shipping weight.
*Trane recommends 1/4-inch rods for hanging suspension.
Table 24: Standard Motor Data (Typical for AA Coil)
Unit Size Volts RPM
(Nominal)
CFM
(Nominal)
Amps
(FLA)
Watts HP
075 115/60/1 1075 750 2.3 222 1/6
100 115/60/1 1075 1000 2.3 222 1/6
125 115/60/1 1075 1250 2.6 287 1/4
150 115/60/1 1075 1500 2.6 287 1/4
200 115/60/1 940 2000 5.7 639 1/3
Table 25: Hi-ESP Motor Data (Typical for AA Coil)
Unit Size Volts RPM
(Nominal)
CFM
(Nominal)
Amps
(FLA)
Watts HP
075 115/60/1 1360 750 4.8 597 1/3
100 115/60/1 1360 1000 4.8 597 1/3
125 115/60/1 1410 1250 7.0 844 1/2
150 115/60/1 1410 1500 7.0 844 1/2
200 115/60/1 1140 2000 8.1 936 3/4
