Performance Data
Vertical Cfg. (A-Coil/D-Coil)
Table P1: VUV; 2-pipe coil with free discharge
VUV
Size
Coil
Type
CFM Cooling (80/67 EAT, 45 EWT/55 LWT) Heating (70 EAT, 180 EWT/140 LWT)
Watt
TMBH SMBH GPM WPD TMBH GPM WPD
075
AA 835 18.5 14.8 3.70 1.5 50.4 2.52 0.6 170
AB 800 22.3 16.7 4.46 2.1 56.5 2.83 0.8 170
AC 800 28.4 19.3 5.67 4.7 63.0 3.15 1.3 170
AD 760 24.1 17.5 4.82 0.9 65.8 3.29 0.4 160
AE 710 25.6 17.5 5.12 1.0 67.5 3.37 0.4 160
100
AA 1085 26.3 19.6 5.27 3.4 66.8 3.34 1.2 205
AB 1050 30.2 21.7 6.03 4.4 75.4 3.77 1.5 205
AC 1040 36.9 24.7 7.37 9.0 82.8 4.14 2.6 205
AD 1005 35.8 24.3 7.16 2.2 88.7 4.44 0.8 205
AE 950 37.3 24.4 7.45 2.3 91.9 4.59 0.8 205
125
AA 1275 34.1 25.6 6.81 6.3 80.5 4.03 2.0 230
AB 1235 38.8 27.9 7.76 7.9 90.9 4.55 2.5 230
AC 1230 42.0 29.0 8.40 4.7 97.6 4.88 1.5 230
AD 1265 49.3 32.6 9.86 4.4 112.6 5.63 1.3 260
AE 1190 50.1 32.1 10.01 4.5 116.0 5.80 1.4 260
150
AA 1655 42.4 30.5 8.49 10.6 102.7 5.13 3.5 290
AB 1595 47.5 33.0 9.50 12.9 115.8 5.79 4.3 290
AC 1585 53.0 35.4 10.61 8.0 124.4 6.22 2.5 290
AD 1530 59.6 38.4 11.93 6.9 136.7 6.84 2.1 280
AE 1455 61.3 38.5 12.26 7.2 142.2 7.11 2.3 280
Table P2: VUV; 4-pipe coil with free discharge
VUV
Size
Coil
Type
CFM Cooling (80/67 EAT, 45 EWT/55 LWT) Heating (70 EAT, 180 EWT/140 LWT)
Watt
TMBH SMBH GPM WPD TMBH GPM WPD
075
DA 800 17.4 13.9 3.47 1.4 50.6 2.53 0.5 170
DC 760 21.3 15.9 4.27 2.0 55.6 2.78 0.6 160
DD 760 27.4 18.6 5.49 4.4 48.7 2.44 0.5 160
DE 710 28.2 18.8 5.64 4.7 52.8 2.64 0.6 160
100
DA 1040 25.6 18.9 5.11 3.3 67.0 3.35 1.0 205
DC 1005 29.1 20.9 5.82 4.1 74.6 3.73 1.2 205
DD 1005 35.9 23.9 7.17 8.5 65.4 3.27 0.9 205
DE 950 37.0 24.5 7.41 9.0 70.3 3.51 1.1 205
125
DA 1230 32.8 24.5 6.56 5.9 81.2 4.06 1.6 230
DC 1265 38.6 27.7 7.72 7.9 94.5 4.73 2.1 260
DD 1265 42.8 29.6 8.56 5.1 82.8 4.14 1.6 260
DE 1190 44.1 30.1 8.82 5.6 90.3 4.51 1.9 260
150
DA 1585 41.4 29.6 8.28 10.1 103.1 5.15 2.6 290
DC 1530 46.3 32.1 9.26 12.3 114.8 5.74 3.2 280
DD 1530 51.9 34.6 10.37 8.0 100.5 5.03 2.5 280
DE 1455 54.1 35.7 10.83 9.0 110.6 5.53 3.0 280
