Trane HUV - Performance Data Electric Heat Coils

80 UV-PRC001-EN
Performance Data
Electric Heat Coils
Table P16: Electric heat capacity
Unit Size Coil Type No of Elem Elem kW Total kW TMBH
075
F3, X3 3 1.95 5.85 19.98
E4, F4, X4 4 1.95 7.80 26.64
E6, F6, X6 6 1.95 11.70 39.96
E7 7 1.95 13.65 46.61
E9 9 1.95 17.55 59.93
100
F3, X3 3 2.60 7.80 26.64
E4, F4, X4 4 2.60 10.40 35.52
E6, F6, X6 6 2.60 15.60 53.27
E7 7 2.60 18.20 62.15
E9 9 2.60 23.40 79.91
125
F3, X3 3 3.25 9.75 33.30
E4, F4, X4 4 3.25 13.00 44.40
E6, F6, X6 6 3.25 19.50 66.60
E7 7 3.25 22.75 77.69
E9 9 3.25 29.25 99.89
150
F3, X3 3 3.80 11.40 38.91
E4, F4, X4 4 3.80 15.20 51.91
E6, F6, X6 6 3.80 22.80 77.86
E7 7 3.80 26.60 90.84
E9 9 3.80 34.20 116.79
200
F3, X3 3 3.80 11.40 38.93
E4, F4, X4 4 3.80 15.20 51.91
E6, F6, X6 6 3.80 22.80 77.86
E7 7 3.80 26.60 90.84
E9 9 3.80 34.20 116.79
