Trane HUV - Performance Data X-Coil Cooling

UV-PRC001-EN 75
Performance Data
X-Coil Cooling
Table P10: 2-pipe, CW cooling data
Unit Size Coil
Type
Cooling (80/67 EAT, 45 EWT/55 LWT)
TMBH SMBH GPM WPD
075
X1 25.20 17.50 5.04 3.80
X2 25.20 17.50 5.04 3.80
X3 25.20 17.50 5.04 3.80
100
X1 34.90 23.70 6.98 8.10
X2 34.90 23.70 6.98 8.10
X3 34.90 23.70 6.98 8.10
125
X1 37.50 26.80 7.50 7.50
X2 37.50 26.80 7.50 7.50
X3 37.50 26.80 7.50 7.50
150
X1 49.50 33.80 9.91 7.40
X2 49.50 33.80 9.91 7.40
X3 49.50 33.80 9.91 7.40
200
X1 68.55 48.58 13.71 13.25
X2 68.55 48.58 13.71 13.25
X3 68.55 48.58 13.71 13.25
