Trane HUV - Performance Data DX-Coil Cooling

78 UV-PRC001-EN
Performance Data
DX-Coil Cooling
DX Coils are rated at the following conditions:
• 95 F ambient outside air temperature
• 25-feet of tubing
• 400 CFM per ton maximum
Table P15: Direct expansion cooling capacity
Unit Size Condensing
unit
EWB
Degrees F
TMBH EDB 72 F
SMBH
EDB 76 F
SMBH
EDB 80 F
SMBH
075
TTB018
10.00 SEER
63 15.70 10.10 12.30 14.60
67 17.00 7.70 10.00 12.20
71 18.30 5.30 7.50 9.80
TTP018
12.00 SEER
63 16.40 10.40 12.70 14.90
67 17.90 8.10 10.30 12.50
71 19.40 5.70 7.90 10.10
TTP024
12.00 SEER
63 20.20 11.80 14.00 16.30
67 22.00 9.50 11.70 13.90
71 23.90 7.10 9.40 11.60
100
TTP024
12.00 SEER
63 21.20 13.80 16.80 19.80
67 23.00 10.60 13.60 16.60
71 24.90 7.30 10.30 13.30
TTB024
10.00 SEER
63 20.00 14.60 18.10 20.50
67 21.60 10.90 14.40 17.90
71 23.30 7.00 10.60 16.90
TTP030
12.00 SEER
63 25.40 16.50 19.90 23.40
67 27.60 12.90 16.30 19.80
71 29.90 9.20 12.60 16.10
125
TTB030
10.00 SEER
63 27.60 19.10 23.50 27.70
67 29.80 14.50 18.90 23.20
71 32.10 9.80 14.10 18.50
TTP030
12.00 SEER
63 27.70 17.40 21.10 24.90
67 30.00 13.40 17.20 20.90
71 32.40 9.40 13.20 16.90
TTA030
10.00 SEER
63 27.80 19.20 23.50 27.80
67 30.00 14.50 18.90 23.20
71 32.30 9.80 14.10 18.50
TTB036
10.00 SEER
63 32.40 20.90 25.20 29.50
67 34.80 16.20 20.50 24.90
71 37.30 11.50 15.80 20.10
