Performance Data
Vertical Cfg. (A-Coil/D-Coil)
Table P3: VUV; 2-pipe coil with high static motor
VUV
Size
Coil
Type
CFM Cooling (80/67 EAT, 45 EWT/55 LWT) Heating (70 EAT, 180 EWT/140 LWT)
Watt
TMBH SMBH GPM WPD TMBH GPM WPD
075
AA 805 18.0 14.4 3.61 1.5 49.1 2.45 0.6 330
AB 785 22.1 16.5 4.42 2.1 55.7 2.79 0.8 330
AC 785 28.3 19.2 5.66 4.7 62.0 3.10 1.3 330
AD 870 28.8 20.6 5.77 1.3 73.6 3.68 0.5 380
AE 830 31.1 21.0 6.23 1.5 77.4 3.87 0.5 380
100
AA 1005 25.8 19.1 5.16 3.3 63.3 3.16 1.1 430
AB 980 29.2 20.9 5.84 4.1 71.7 3.58 1.4 430
AC 980 36.0 24.0 7.19 8.6 79.1 3.95 2.4 430
AD 1055 37.8 25.7 7.57 2.4 92.3 4.62 0.8 465
AE 1010 40.0 26.2 8.00 2.7 96.9 4.84 0.9 465
125
AA 1365 36.4 27.6 7.29 7.1 84.5 4.22 2.2 530
AB 1335 41.3 29.8 8.25 8.8 96.3 4.81 2.8 530
AC 1330 45.6 31.8 9.12 5.5 103.6 5.18 1.6 530
AD 1300 50.7 33.6 10.14 4.6 115.1 5.75 1.4 520
AE 1250 53.3 34.2 10.65 5.1 121.0 6.05 1.5 510
150
AA 1550 43.1 31.0 8.62 10.9 98.1 4.90 3.2 565
AB 1525 47.6 33.1 9.51 12.9 112.1 5.60 4.1 565
AC 1520 53.2 35.5 10.64 8.1 120.4 6.02 2.4 565
AD 1490 60.8 39.3 12.16 7.1 133.8 6.69 2.0 565
AE 1805 76.5 48.5 15.30 10.8 170.9 8.54 3.2 680
Table P4: VUV; 4-pipe coil with high static motor
VUV
Size
Coil
Type
CFM Cooling (80/67 EAT, 45 EWT/55 LWT) Heating (70 EAT, 180 EWT/140 LWT)
Watt
TMBH SMBH GPM WPD TMBH GPM WPD
075
DA 785 17.3 13.8 3.46 1.4 49.9 2.49 0.5 330
DC 870 24.2 18.2 4.84 2.5 61.4 3.07 0.8 380
DD 870 30.7 21.0 6.14 5.4 53.6 2.68 0.6 380
DE 830 32.4 21.7 6.47 5.9 59.3 2.97 0.7 380
100
DA 980 24.9 18.4 4.98 3.1 64.2 3.21 0.9 430
DC 1055 30.5 21.9 6.10 4.5 77.3 3.87 1.3 465
DD 1055 37.4 25.1 7.49 9.2 67.7 3.39 1.0 465
DE 1010 39.3 26.0 7.86 10.0 73.6 3.68 1.2 465
125
DA 1330 35.2 26.6 7.05 6.7 85.8 4.29 1.7 530
DC 1300 39.6 28.5 7.92 8.2 96.5 4.82 2.2 520
DD 1300 43.9 30.4 8.77 5.3 84.4 4.22 1.7 520
DE 1250 46.7 32.0 9.34 6.2 93.7 4.68 2.0 510
150
DA 1520 41.5 29.7 8.30 10.2 100.1 5.00 2.5 565
DC 1490 47.1 32.8 9.42 12.7 112.6 5.63 3.1 565
DD 1490 52.8 35.2 10.55 8.3 98.6 4.93 2.4 565
DE 1805 66.4 44.4 13.28 13.0 129.5 6.48 4.0 680
