70 UV-PRC001-EN
Performance Data
Horizontal Cfg. (A-Coil)
Table P5: HUV; 2-pipe coil with free discharge
VUV
Size
Coil
Type
CFM Cooling (80/67 EAT, 45 EWT/55 LWT) Heating (70 EAT, 180 EWT/140 LWT)
Watt
TMBH SMBH GPM WPD TMBH GPM WPD
075
AA 875 19.0 15.3 3.8 1.6 52.0 2.60 0.7 160
AB 825 21.1 16.2 4.22 1.9 57.8 2.89 0.8 160
AC 815 27.9 19.2 5.58 4.6 63.9 3.19 1.4 160
AD 780 21.0 16.6 4.20 0.7 67.2 3.36 0.4 160
AE 760 19.9 15.5 3.97 0.6 71.7 3.58 0.5 160
100
AA 1090 25.6 19.0 5.13 3.3 67.0 3.35 1.2 210
AB 1030 27.7 20.0 5.54 3.8 74.4 3.72 1.5 210
AC 1025 34.6 23.1 6.93 8.0 81.9 4.09 2.5 210
AD 975 31.0 21.4 6.19 1.7 86.6 4.33 0.7 210
AE 1015 31.7 21.6 6.35 1.8 97.3 4.87 0.9 210
125
AA 1240 34.1 25.5 6.82 6.3 79.0 3.95 1.9 225
AB 1300 38.5 27.7 7.69 7.8 94.4 4.72 2.7 240
AC 1290 43.2 30.0 8.65 5.0 101.2 5.06 1.6 240
AD 1240 47.1 31.4 9.42 4.0 110.7 5.54 1.3 240
AE 1265 47.1 31.0 9.43 4.1 122.3 6.11 1.6 265
150
AA 1600 42.9 31.7 8.58 10.8 100.3 5.01 3.3 260
AB 1525 44.9 31.8 8.98 11.7 112.1 5.60 4.1 260
AC 1510 51.0 34.3 10.20 7.5 119.9 5.99 2.4 260
AD 1600 56.9 36.9 11.39 6.3 141.8 7.09 2.3 295
AE 1485 55.3 35.3 11.06 6.0 144.8 7.24 2.3 295
200
AA 2085 51.1 38.9 10.23 14.7 120.0 6.00 4.6 570
AB 1985 56.3 40.9 11.27 17.5 135.4 6.77 5.7 560
AC 1970 63.9 44.1 12.77 11.2 146.4 7.32 3.4 560
AD 1885 71.0 46.8 14.20 9.5 161.7 8.08 2.9 540
AE 1785 68.6 44.3 13.73 8.9 169.3 8.47 3.1 530
