Trane HUV - Performance Data Horizontal Cfg. (D-Coil)

UV-PRC001-EN 71
Performance Data
Horizontal Cfg. (D-Coil)
Table P6: HUV; 4-pipe coil with free discharge
VUV
Size
Coil
Type
CFM Cooling (80/67 EAT, 45 EWT/55 LWT) Heating (70 EAT, 180 EWT/140 LWT)
Watt
TMBH SMBH GPM WPD TMBH GPM WPD
075
DA 815 18.1 14.5 3.63 1.5 51.2 2.56 0.5 160
DC 780 20.3 15.6 4.06 1.8 56.7 2.83 0.7 160
DD 780 27.1 18.6 5.42 4.3 49.7 2.48 0.5 160
DE 760 27.7 18.7 5.54 4.5 55.6 2.78 0.6 160
100
DA 1025 24.7 18.2 4.95 3.1 66.3 3.32 1.0 210
DC 975 26.3 18.9 5.25 3.4 73.0 3.65 1.2 210
DD 975 33.3 22.1 6.66 7.5 64.0 3.20 0.9 210
DE 1015 35.5 23.4 7.09 8.4 73.9 3.69 1.2 210
125
DA 1290 34.7 26.0 6.93 6.5 84.0 4.20 1.7 240
DC 1240 37.6 27.1 7.52 7.5 93.1 4.66 2.0 240
DD 1240 42.4 29.4 8.48 5.0 81.6 4.08 1.6 240
DE 1265 45.3 31.0 9.06 5.8 94.5 4.73 2.1 265
150
DA 1510 41.0 30.0 8.20 9.9 99.6 4.98 2.5 260
DC 1600 44.9 31.8 8.98 11.7 118.6 5.93 3.4 295
DD 1600 51.1 34.4 10.23 7.8 103.7 5.19 2.7 295
DE 1485 52.9 35.2 10.58 8.6 112.3 5.61 3.1 295
200
DA 1970 49.6 37.6 9.93 13.9 119.8 5.99 3.5 560
DC 1885 54.8 39.7 10.96 16.6 133.6 6.68 4.3 540
DD 1885 62.4 42.9 12.47 11.2 116.2 5.81 3.3 540
DE 1785 64.8 43.8 12.96 12.5 128.5 6.43 4.0 530
