72 UV-PRC001-EN
Performance Data
Horizontal Cfg. (A-Coil)
Table P7: HUV; 2-pipe coil with high static motor
VUV
Size
Coil
Type
CFM Cooling (80/67 EAT, 45 EWT/55 LWT) Heating (70 EAT, 180 EWT/140 LWT)
Watt
TMBH SMBH GPM WPD TMBH GPM WPD
075
AA 780 17.3 13.9 3.47 1.4 48.0 2.40 0.6 305
AB 760 19.7 15.1 3.93 1.7 54.4 2.72 0.7 305
AC 755 26.3 18.0 5.25 4.1 60.2 3.01 1.2 305
AD 740 18.9 15.3 3.78 0.6 64.2 3.21 0.4 305
AE 795 22.2 16.8 4.44 0.8 74.5 3.73 0.5 335
100
AA 1115 28.5 21.3 5.70 3.9 68.0 3.40 1.3 500
AB 1090 31.4 22.8 6.29 4.7 77.5 3.88 1.6 500
AC 1085 39.1 26.4 7.83 10.0 85.5 4.28 2.7 500
AD 1055 37.4 25.9 7.49 2.4 92.4 4.62 0.8 500
AE 1005 36.0 24.4 7.20 2.2 96.4 4.82 0.9 480
125
AA 1255 35.0 26.3 7.01 6.6 79.6 3.98 2.0 470
AB 1225 38.1 27.5 7.62 7.7 90.4 4.52 2.5 470
AC 1220 42.8 29.7 8.57 4.9 96.9 4.85 1.4 470
AD 1350 51.6 34.6 10.32 4.8 118.7 5.93 1.5 525
AE 1295 50.0 32.9 10.00 4.5 124.8 6.24 1.6 525
150
AA 1490 38.7 28.1 7.73 9.0 95.4 4.77 3.1 550
AB 1450 41.2 29.0 8.23 10.0 108.0 5.40 3.8 550
AC 1445 46.9 31.3 9.38 6.5 115.8 5.79 2.2 550
AD 1715 56.6 36.6 11.32 6.3 150.0 7.50 2.5 680
AE 1635 54.1 34.5 10.82 5.8 157.2 7.86 2.7 680
200
AA 2095 50.4 38.3 10.08 14.3 120.4 6.02 4.6 810
AB 2005 55.4 40.2 11.08 17.0 136.4 6.82 5.8 790
AC 1990 62.7 43.2 12.54 10.8 147.4 7.37 3.4 790
AD 1895 69.1 45.5 13.82 9.0 162.4 8.12 2.9 770
AE 1770 66.5 42.9 1331 8.4 168.1 8.40 3.1 750
