Trane HUV - Dimensional Data Gravity Relief Damper

UV-PRC001-EN 117
Size A B C
050 30 1/8" 29 7/8" 7 3/4"
075 42 1/8" 41 7/8" 13 3/4"
100 54 1/8" 53 7/8" 16 3/4"
125 66 1/8" 65 7/8" 19 3/4"
150/200 78 1/8" 77 7/8" 22 3/4"
Dimensional Data
Gravity Relief Damper
