Model Number
Horizontal Unit Ventilator
DIGIT 1-3: UNIT CONFIGURATION
HUV = Horizontal Unit Ventilator
DIGIT 4: DEVELOPMENT
SEQUENCE
C = Third Generation
DIGIT 5-7: NOMINAL CAPACITY
075 = 750 CFM
100 = 1000 CFM
125 = 1250 CFM
150 = 1500 CFM
200 = 2000 CFM
DIGIT 8: UNIT INCOMING POWER
SUPPLY
1 = 120V/1-Phase Power Supply
2 = 208V/1-Phase Power Supply
3 = 208V/3-Phase Power Supply
4 = 240V/1-Phase Power Supply
5 = 240V/3-Phase Power Supply
6 = 277V/1-Phase Power Supply
8 = 480V/3-Phase 4-Wire Power
Supply
DIGIT 9: PSC MOTOR/
DISCONNECT
0 = Std. Motor, No Disconnect
1 = Std. Motor with Non-Fused
Toggle
2 = Std. Motor with Manual Starter
3 = Std. Motor with Circuit Breaker
(E-Ht)
A = Hi-ESP Motor, No Disconnect
B = Hi-ESP Motor with Non-Fused
Toggle
C = Hi-ESP Motor with Manual
Starter
D = Hi-ESP Motor with Circuit Break-
er (E-Ht)
DIGIT 10&11: DESIGN SEQUENCE
E0 = Factory Assigned
DIGIT 12&13: COIL
CONFIGURATION
(Single Coil Options)
AA = 2-Pipe CW/HW Coil
AB = 2-Pipe CW/HW Coil
AC = 2-Pipe CW/HW Coil
AD = 2-Pipe CW/HW Coil
AE = 2-Pipe CW/HW Coil
H1 = 2-Pipe HW Coil
H2 = 2-Pipe HW Coil
H3 = 2-Pipe HW Coil
H4 = 2-Pipe HW Coil
H5 = 2-Pipe HW Coil
H6 = 2-Pipe HW Coil
K1 = 2-Pipe Steam Distributing Coil
K2 = 2-Pipe Steam Distributing Coil
E4 = 4-Element Electric Heat Coil
E6 = 6-Element Electric Heat Coil
E7 = 7-Element Electric Heat Coil
E9 = 9-Element Electric Heat Coil
F0 = 2-Pipe Direct Expansion Coil
(Coupled Coil Options)
DA = 4-Pipe CW/Preheat HW Coil
DC = 4-Pipe CW/Preheat HW Coil
DD = 4-Pipe CW/Preheat HW Coil
DE = 4-Pipe CW/Preheat HW Coil
DK = 4-Pipe CW/Steam Preheat
X3 = 2-Pipe CW/3-Element Preheat
X4 = 2-Pipe CW/4-Element Preheat
X6 = 2-Pipe CW/6-Element Preheat
FA = 4-Pipe DX/HW Preheat Coil
FK = 4-Pipe DX/Preheat Steam Coil
F3 = 2-Pipe DX/3-Element Preheat
F4 = 2-Pipe DX/4-Element Preheat
F6 = 2-Pipe DX/6-Element Preheat
R1 = 4-Pipe CW/Reheat HW Coil
R2 = 4-Pipe CW/Reheat HW Coil
DIGIT 14: COIL CONNECTIONS
(Single Coil Options)
A = Right Hand Supply
B = Left Hand Supply
(Coupled Coil Options)
C = Left Hand Cool/Right Hand Heat
D = Right Hand Cool/Left Hand Heat
DIGIT 15: CONTROL TYPES
0 = None/Field Installed Controls
(Terminal Unit Controller,
Standalone)
A = TUC Std. Package
B = TUC Std. Package w/ Low Temp
C = TUC Std. Package w/Time Clock
D = TUC Std. Package w/Low Temp
& Time Clock
(Terminal Unit Controller,
Integrated Comfort System)
E = TUC Std. Package
F = TUC Std. Package w/Fan & Filter
Status
G = TUC Std. Package w/Low Temp
H = TUC Std. Package w/Low Temp,
Fan & Filter Status
(Pneumatic Control System)
M = Pneumatic Room Control w/
Low Temp
P = Pneumatic Zone Control w/Low
Temp
(Tracer
TM
ZN520,
Standalone System)
Q = Tracer ZN520 Std. Package
R = Tracer ZN520 Std. Package w/
Low Temp
T = Tracer ZN520 Std. Package w/
Time Clock
U = Tracer ZN520 Std. Package w/
Low Temp & Time Clock
(Tracer
TM
ZN520,
Integrated Comfort System)
V = Tracer ZN520 ICS
W = Tracer ZN520 ICS w/Low Temp
X = Tracer ZN520 ICS w/Fan Status
Proof
Y = Tracer ZN520 ICS w/Low Temp &
Fan Status Proof
(End Device Package)
8 = DDC Std. Package
9 = DDC Std. Package w/Low Temp
Horizontal Unit Ventilator
10 15
HUV C 125 2 0 A0 AA B 0 0 0 0 0 1 1 A 0 1 0 0 0 0 1 1 1 0
5 20 25 30
