Table 6. SCWF/SIWF Refrigerant circuits, number of compressors by circuit
Circuit
Unit Size 1 2 3 4 5 6
20/22/25 Ton
1- 10T 1- 10T
N/A N/A N/A N/A
29/32 Ton
1- 15T 1- 10T
N/A N/A N/A N/A
35/38 Ton
1- 10T 1- 10T 1- 10T
N/A N/A N/A
42/46 Ton
1- 15T 1- 10T 1- 10T
N/A N/A N/A
52/58 Ton
1- 15T 1- 15T 1- 15T
N/A N/A N/A
60/72 Ton
1- 15T 1- 15T 1- 15T 1- 10T
N/A N/A
80 Ton 1- 15T 1- 15T 1- 15T 1- 15T
N/A N/A
90 Ton 1- 15T 1- 15T 1- 15T 1- 15T 1- 15T
100 Ton 1-15T 1-15T 1-15T 1-15T 1-10T 1-10T
110 Ton 1- 15T 1- 15T 1- 15T 1- 15T 1- 15T 1- 15T
Note: This table depicts compressor location in unit, plan view from left corner.
Table 7. SCRF/SIRF Refrigerant circuits, number of compressors by circuit
Circuit
Unit Size 1 2
25/29 Ton
1-15T 1-10T
30/35 Ton
2-10T 1-10T
40 Ton
1-10T, 1-15T
1-10T
50 Ton 2-15T 1-15T
60 Ton 2-15T 2-15T
Note: This table depicts compressor location in unit, plan view from left corner.
Table 8. Filter data, water-cooled units models SCWF & SIWF
Unit Size 20- 38 tons 40-85 tons 90-110 tons
Number - Size (In.)
8 - 20 x 18 12 - 25 x 20 15 - 24 x 24
4 - 20 x 20 6 - 20 x 20 3 - 24 x 12
Units With Hot Water Or Steam
Number - Size (In.)
4 - 16 x 20 4 - 25 x 20
n/a
4 - 20 x 20 2 - 20 x 20
4 - 18 x 20 8 - 25 x 16
4 - 20 x 16
Table 9. Filter data, air-cooled units models SCRF & SIRF
Unit size 20- 35 tons 40-60 tons
Number - Size (in.)
8 - 20 x 18 12 - 25 x 20
4 - 20 x 20 6 - 20 x 20
Units With Hot Water Or Steam
