SCXF-SVX01Q-EN
17
Table 3. SCRF/SIRF Air-cooled self-contained (continued)
Unit Size 25 29 30 35 40 50 60
CCRC/CIRC Unit Match
29 29 35 35 40 50 60
Notes:
1. Compressors are Trane 3-D™ scroll.
2. All units operate with R-410A. Units ship with a dry nitrogen holding charge. Field refrigerant system charge required. Refer to Table 4, p. 17 for
amounts required.
3. Maximum cfm limits are set to prevent moisture carryover on the evaporator coil.
4. Minimum cfm limits are set to ensure stable thermal expansion valve operation at low load conditions.
Table 4. SCRF/SIRF Air–cooled self–contained and CCRC/CIRC remote air-cooled condenser refrigerant data
SCRF/SIRF & CCRC/CIRCUnit
Size
25/29 29/29 30/35 35/35 40/40 50/50 60/60
No. of Refrigerant Circuits
2 2 2 2 2 2 2
Operating Charge - lbs. R-410A
56.2/38.0 56.2/38.0 71/35.5 75/37.5 86.5/39.5 100/52
101.5/
101.5
Operating Charge - kg R-410A
23.1/17 23.1/17 32.2/16.1 34/17 39.2/17.9 44.5/22.7 46/46
Cond. Storage Cap. - lbs. R-410A
51/37 51/37 74/37 74/37 74/51 102/51 102/102
Cond. Storage Cap. - kg R-410A
23.1/16.8 23.1/16.8 33.6/16.8 33.6/16.8 33.6/23.1 46.3/23.1 46.3/46.3
Notes:
1. Refrigerant charges are listed as circuit 1 circuit 2 and provide only an estimate. Final charge requires sound field charging practice.
2. Operating charge is for entire system, which includes the air–cooled self–contained, remote air–cooled condenser, and 25 feet of interconnecting
refrigerant piping.
3. At conditions of 95° F (35° C), condenser storage capacity is 95% full.
4. To determine the correct amount of refrigerant needed for a particular application, reference the Trane Reciprocating Refrigeration Manual.
Table 5. SCWF/SIWF water volumes
Unit Size
Water Volume in U.S. Gallons / Liters
W/o Economizer
With Mech. Cleanable Econ With Chem. Cleanable Econ
Gallons Liters Gallons Liters Gallons Liters
20 9.0 34.1 17.4 65.9 16.9 64.0
22 9.0 34.1 17.4 65.9 16.9 64.0
25 9.0 34.1 17.4 65.9 16.9 64.0
29 9.0 34.1 20.5 77.6 18.8 71.2
32 9.0 34.1 20.5 77.6 18.8 71.2
35 10.0 37.9 21.9 82.9 20.2 76.5
38 10.0 37.9 21.9 82.9 20.2 76.5
42 15.0 56.8 32.2 121.9 31.4 118.9
46 15.0 56.8 32.2 121.9 31.4 118.9
52 15.0 56.8 36.9 139.7 35.9 135.9
58 15.0 56.8 36.9 139.7 35.9 135.9
65 16.0 60.6 37.9 143.5 36.9 139.7
72 16.0 60.6 37.9 143.5 36.9 139.7
80 16.0 60.6 37.9 143.5 36.9 139.7
90 22.5 85.2 50.1 189.6
N/A N/A
100 23.0 87.1 50.6 191.5
N/A N/A
110 24.0 90.8 51.6 195.3
N/A N/A
