Table 9. Filter data, air-cooled units models SCRF & SIRF (continued)
Unit size 20- 35 tons 40-60 tons
Number - Size (in.)
4 - 16 x 20 4 - 25 x 20
4 - 20 x 20 2 - 20 x 20
4 - 18 x 20 8 - 25 x 16
N/A
4 - 20 x 16
Table 10. Self-contained heating coil
Unit Size SCWF 20 - 38 SCWF 42 - 80 SCRF 20 - 35 SCRF 40 - 60
Steam Coil
Coil Type
NS NS NS NS
Rows 1 1 1 1
No./Size (inches) (2) 24 x 58 (2) 30 x 81 (2) 24 x 58) (2) 30 x 81
No./Size (mm) (2) 609.6 x 1473.2 (2) 762 x 2057.4 (2) 609.6 x 1473.2 (2) 762 x 2057.4
FPF 42 42 42 42
Hot Water Coil
Coil Type
5W 5W 5W 5W
Rows 1 or 2
N/A N/A N/A
No./Size (inches) (2) 24 x 58 (2) 30 x 81 (2) 24 x 58 (2) 30 x8 1
No./Size (mm) (2) 609.6 x 1473.2 (2) 762 x 2057.4 (2) 609.6 x 1473.2 (2) 762 x 2057.4
FPF 80 or 108 80 or 108 80 or 108 80 or 108
Notes:
1. Hot water and steam heating coils have Prima-Flo® fins without turbulators.
2. For coil capacities, use TOPSS™ (Trane Official Product Selection Program).
3. Full capacity coils consist of two coils stacked and piped in parallel.
Table 11. Waterside economizer coil physical data
Model Unit Size
Type
Rows FPF
Height
(in)
Length
(in)
SCXF
20, 22 & 25 Chemically Cleanable
2 108 40 78.5
SCXF
20, 22 & 25
Mechanical Cleanable 2 108 40 78.5
SCXF
20, 22 & 25 Chemically Cleanable
4 108 40 78.5
SCXF
20, 22 & 25
Mechanical Cleanable 4 108 40 78.5
SCXF 29 & 32
Chemically Cleanable
2 108 55 78.5
SCXF 29 & 32 Mechanical Cleanable 2 108 55 78.5
SCXF 29 & 32 Mechanical Cleanable 4 108 55 78.5
SCXF 29 & 32
Chemically Cleanable
4 108 55 78.5
SCXF 35 & 38
Chemically Cleanable
2 108 57.5 78.5
SCXF 35 & 38 Mechanical Cleanable 2 108 57.5 78.5
SCXF 35 & 38
Chemically Cleanable
4 108 57.5 78.5
SCXF 35 & 38 Mechanical Cleanable 4 108 57.5 78.5
SCXF 42 & 46
Chemically Cleanable
2 144 55 101
