Table 5-4
Filter Data
Panel-Type Filters Bag-Type Filters Cartridge Filters Panel-Type Prefilters
Unit Model (Note 1) (Note 2) (box-type) (Note 2) (Note 3)
Qty Size of each Qty. Size of each Qty. Size of each Qty. Size of each
S_HF-C20 & 12 20 X 20 X 2 4 12 X 24 X 19 4 12 X 24 X 12 4 12 X 24 X 2
C25 3 24 X 24 X 19 3 24 X 24 X 12 3 24 X 24 X 2
S_HF-C30 16 20 X 20 X 2 2 12 X 24 X 19 2 12 X 24 X 12 2 12 X 24 X 2
6 24 X 24 X 19 6 24 X 24 X 12 6 24 X 24 X 2
S_HF-C40 16 20 X 25 X 2 5 12 X 24 X 19 5 12 X 24 X 12 5 12 X 24 X 2
6 24 X 24 X 19 6 24 X 24 X 12 6 24 X 24 X 2
S_HF-C50 & 20 20 X 25 X 2 3 12 X 24 X 19 3 12 X 24 X 12 3 12 X 24 X 2
C55 9 24 X 24 X 19 9 24 X 24 X 12 9 24 X 24 X 2
S_HF-C60, 35 16 X 20 X 2 6 12 X 24 X 19 6 12 X 24 X 12 6 12 X 24 X 2
C70 & C75 8 24 X 24 X 19 8 24 X 24 X 12 8 24 X 24 X 2
S_HG-C90 & 25 24 X 24 X 2 3 12 X 24 X 19 3 12 X 24 X 12 3 20 X 24 X 2
S_HG-D11 15 24 X 24 X 19 15 24 X 24 X 12 15 24 X 24 X 2
S_HG-D12 & 25 24 X 24 X 2 3 12 X 24 X 19 3 12 X 24 X 12 3 20 X 24 X 2
S_HG-D13 15 24 X 24 X 19 15 24 X 24 X 12 15 24 X 24 X 2
Notes:
1. Dimensions shown for “Panel-Type Filters”apply to “Throw away”, “Cleanable Wire Mesh”,
and “High Efficiency Throw away” Filters.
2. S_HF units ordered with “Bag-Type Filters” or “Cartridge Filters” (box-type) include a bank
of “Panel-Type Prefilters”.
3. The same “Panel-Type Prefilters” are used with “Bag-Type” and “Cartridge (box-type)” filters.
Table 5-5
"Wet Heat" Coil Fin Data
Total Coil Fins Fins
Coil Coil Face Area per per
Model Type Rows (sq.ft.) Foot Foot
SLHF-C20, WC
C25 & C30 Prima Flo 2 13.75 80 110
(hot water)
SLHF-C40, WC
C50 & C55 Prima Flo 2 19.25 80 110
(hot water)
SLHF-C60, WC
C70 & C75 Prima Flo 2 26.25 80 110
(hot water)
SLHG-C90, WC
D11, D12 Prima Flo 2 17.5 (2) 80 110
& D13 (hot water)
SSHF-C20, NS 1 13.75 42 96
C25 & C30 (steam)
SSHF-C40, NS 1 13.75 (1) 42 96
C50 & C55 (steam) 5.5 (1)
SSHF-C60, NS 1 18.75 (1) 42 72
C70 & C75 (steam) 7.5 (1)
SLHG-C90, NS 1 17.5 (2) 52 96
D11, D12 (steam)
& D13
Note:
To determine unit heatin
g
ca
p
acit
y
(
i.e., “low heat” or “hi
g
h heat”
)
,
see Digit 9 of the model number stamped on the unit nameplate.
Service & Maintenance (Continued)
