Trane IntelliPak

105
Service & Maintenance (Continued)
Table 5-6
Grease Recommendations
Recommended
Recommended Grease Operating Range
Exxon Unirex #2
Mobil 532 -20 F to 250 F
Mobil SHC #220
Texaco Premium RB
Table 5-7
Refrigerant Coil Fin Data
Coil Fins Coil Face
Coil Fin Tube Coil
p
er Area Tube
Model T
yp
e Confi
g
. Dia. Rows Foot
(
s
q
. ft.
)
T
yp
e
S*HF-C20 Evaporator wavy-3B 0.5" 2 148 20.30 I-F
Hi-Cap Evaporator wavy-3B 0.5" 4 148 20.30 I-F
Condenser wavy-3B 0.375" 3 156 35.00 smooth
S*HF-C25 Evaporator wavy-3B 0.5" 2 148 20.30 I-F
Hi-Cap Evaporator wavy-3B 0.5" 4 148 20.30 I-F
Condenser wavy-3B 0.375" 3 156 35.00 smooth
Hi-Eff Condenser wavy-3B 0.375" 4 156 35.00 smooth
S*HF-C30 Evaporator wavy-3B 0.5" 3 148 24.40 I-F
Hi-Cap Evaporator wavy-3B 0.5" 4 148 24.40 I-F
Condenser wavy-3B 0.375" 3 168 46.30 smooth
Hi-Eff Condenser wavy-3B 0.375" 4 168 46.30 smooth
S*HF-C40 Evaporator wavy-3B 0.5" 2 148 32.50 I-F
Hi-Cap Evaporator wavy-3B 0.5" 4 148 32.50 I-F
Condenser wavy-3B 0.375" 3 168 63.20 smooth
S*HF-C50 Evaporator wavy-3B 0.5" 3 148 37.90 I-F
Hi-Cap Evaporator wavy-3B 0.5" 4 148 37.90 I-F
Condenser wavy-3B 0.375" 3 168 70.00 smooth
Hi-Eff Condenser wavy-3B 0.375" 4 168 70.00 smooth
S*HF-C55 Evaporator wavy-3B 0.5" 3 148 37.90 I-F
Hi-Cap Evaporator wavy-3B 0.5" 4 148 37.90 I-F
Condenser wavy-3B 0.375" 4 144 70.00 smooth
S*HF-C60 Evaporator wavy-3B 0.5" 2 164 43.10 I-F
Hi-Cap Evaporator wavy-3B 0.5" 4 148 43.10 I-F
Condenser wavy-3B 0.375" 4 168 88.00 smooth
S*HF-C70 Evaporator wavy-3B 0.5" 3 180 43.10 I-F
Hi-Cap Evaporator n/a n/a n/a n/a n/a n/a
Condenser wavy-3B 0.375" 4 168 88.00 smooth
S*HF-C75 Evaporator wavy-3B 0.5" 4 148 43.10 I-F
Hi-Cap Evaporator wavy-3B 0.5" 5 148 43.10 I-F
Condenser wavy-3B 0.375" 4 168 88.00 smooth
S*HG-C90 Evaporator wavy-3B 0.5" 3 148 59.30 I-F
Hi-Cap Evaporator wavy-3B 0.5" 5 148 59.30 I-F
Condenser wavy-3B 0.375" 3 156 152.00 smooth
Hi-Eff Condenser wavy-3B 0.375" 4 156 152.00 smooth
S*HG-D11 Evaporator wavy-3B 0.5" 3 180 60.40 I-F
Hi-Cap Evaporator wavy-3B 0.5" 5 148 60.40 I-F
Condenser wavy-3B 0.375" 4 156 152.00 smooth
S*HG-D12 Evaporator wavy-3B 0.5" 5 148 60.40 I-F
Hi-Cap Evaporator n/a n/a n/a n/a n/a n/a
Condenser wavy-3B 0.375" 4 156 152.00 smooth
S*HG-D13 Evaporator wavy-3B 0.5" 5 148 60.40 I-F
Hi-Cap Evaporator n/a n/a n/a n/a n/a n/a
Condenser wavy-3B 0.375" 4 156 152.00 smooth
