IPG108D / IPG108E:
Power supply: 24V AC/DC
Digital inputs: 11 opto-insulated at 24Volt AC current on the contact
Analog inputs : 6 configurables: 0÷5V, 4÷20mA, NTC, PTC, digital input
Analog outputs Opto-Insulated: 4 configurables: 0÷10V signal, external relay driving
Relay outputs
8 x 5(2) A @ 250V SPST
Remote terminal
N° 1 output for connection of up to two remote terminals (100M)
RTC
LED DISPLAY INTEGRATED (IPG108E)
Serial outputs
1 USB; Bacnet TCP/IP using USB/Ethernet adapter
1 RS485 master with Mod_BUS communication protocol or 1 LAN to connect I/O expansion module
1 RS485 slave with Mod_BUS or with Bacnet MSTP communication protocol
