Technical Specifications
IPG315D:
Power supply: 24V AC/DC
Digital inputs: 20 opto-insulated at 24Volt AC current on the contact
Analog inputs: 10 configurables: 0÷5V, 4÷20mA, NTC, PTC, digital input
Analog outputs Opto-Insulated: 2 configurables: 0÷10V, external relay driving, PWM signal
4 configurables: 0÷10V signal, external relay driving
Relay outputs: 10 x 5(2) A @ 250V SPST + 5 SSR type
Remote terminal N° 1 output for connection of up to two remote terminals (100M)
RTC
Serial outputs
1 USB
1 Ethernet with Bacnet TCP/IP communication protocol
1 connecter for/GSM modem /XWEB modem
1 RS485 master with Mod_BUS communication protocol
1 RS485 slave with Mod_BUS or Bacnet MSTP communication protocol
1 CANbus to connect I/O expansion modules
