Submenu
The LCD display provides a simple and immediate interaction with the unit.
Pressing the "SERVICE" button, you can enter in the screens dedicated to the displaying and/or to the
configuration of components and user parameters of the unit.
Using the arrow keys you can select the below areas reserved for displaying the features of each
component. The areas used for this application are:
Parameters programming
Time bands programming
Current compressors parameters display
Fans and pumps current parameters display
Alarm display
Alarm history display
Defrost status display
Inputs and outputs status display
Auxiliary outputs status display
Recovery parameters display (Only for chiller with recovery)
Display setting and di log files management
Access to the link mentioned above is carried out by pressing the "ENTER" key after highlighting the
desired icon using the or buttons. By pressing the "ESC" anytime you return to the main
screen.
