7
Fig.9 INDOOR COIL AND DRAIN PAN SET-UP
HORIZONTAL ADAPTER KIT
VAPOR LINE CONNECTION
LIQUID LINE CONNECTION
PRIMARY DRAIN
CONNECTION
VERTICAL DRAIN PAN
AUXILIARY HORIZONTAL
AUXILIARY UPFLOW/DOWNFLOW
STRAPS
REAR WATER CATCHER
TOP AIR STOP
DRAIN CONNECTION
DRAIN CONNECTION
FRONT WATER CATCHER
STRAPS
THIS SYSTEM IS CHARGED WITH NITROGEN BEFORE SHIPMENT
42K,48K,60K
36K,30K
24k,18K
A
1:4
A
RAILS
RAILS
DETAIL A
ENSURE THE RETAINING
CHANNEL IS FULLY ENGAGED
WITH THE COIL RAIL.
Fig.8 VERTICAL DOWNFLOW & HORIZONTAL LEFT APPLICATIONS
(lower front service panel removed “view”.)
AIRFLOW
AIRFLOW
