Picco R32 Air/Water heat pumps with axial fans
16
DIMENSIONS
Model Picco R32 06A / 08A / SL08A


E
IN
OUT
830
120 657 140
354
104
63
226
95
394
918
E
Model Picco R32 10 / 10T / 12 / SL12 / 12T / SL12T


1047
134 673 134
403
87
936
109
174
455
311 144
E E
OUT
IN
