Trane Picco R32-SL16T - Unit and Auxiliary Electrical Data; Operating Limits; Evaporator Water Flow Rate Limits

Picco R32 Air/water inverter heat pumps with axial fans
41

(1) Cooling: outdoor air temperature 35°C; in/out water temperature 12/7°C.
(2) Cooling: outdoor air temperature 35°C; in/out water temperature 23/18°C.
(3) Heang: outdoor air temperature 7°C db 6°C db; in/out water temp 30/35°C.
(4) Heang: outdoor air temperature 7°C db 6°C db; in/out water temp 40/45°C.
(5) Cooling: in/out water temperature 7/12°C.
(6) Heang: average climac condions; Tbiv=-7°C; in/out water temp 30/35°C.
(7) Indicave data subject to changes. For the correct value, always refer to the technical label on the unit.
(8) Calculated for a decrease in system water temperature of 20°C with a defrost cycle lasng 6 minutes.
(9) Sound power level: heang mode condion (3) according to EN 12102-1:2013; value calculated based on measurements made in accordance
with standard UNI EN ISO 9614-1.
(10) Sound power level: heang mode at paral load according to annex A of EN 12102:2017; value determined on the basis of measurements
carried out in accordance with UNI EN ISO 9614-1, in compliance with the requirements of Eurovent and Heat Pump Keymark cercaon.
(*) acvang the maximum Hz funcon.


14825.
UNIT AND AUXILIARY ELECTRICAL DATA
Unit power supply V/~/Hz 400/3PH+PE/50
On board controller circuit V/~/Hz 12/1/50
Remote controller circuit V/~/Hz 12/1/50
Fans power supply V/~/Hz 400/3PH+PE/50



12. OPERATING LIMITS
EVAPORATOR WATER FLOW RATE





circuit.



Model Picco R32 06A  10 10T   14 14T   18T
Minimum water ow to be assured in
chiller mode (condion (1) technical
sheet) [l/s]
0,15 0,17 0,23 0,25 0,34 0,34 0,41
Maximum water ow to be assured in
chiller mode (condion (1) technical
sheet) [l/s]
0,40 0,46 0,60 0,68 0,92 0,92 0,92
[l/s] Minimum ow switch water ow
rate* [l/s]
0,117 0,117 0,153 0,153 0,153 0,262 0,262
Maximum ow switch water ow
rate* [l/s]
0,132 0,132 0,175 0,175 0,175 0,293 0,293













