Picco R32 Air/Water heat pumps with axial fans
38
TECHNICAL SPECIFICATIONS Unit
Picco R32
14T 16 16T 18T
Cooling
Cooling capacity (1)
kW 6,87 / 11,5 / 12,1*
5,99 / 13,8 /
14,5*
5,99 / 13,8 /
14,5*
6,86 / 15,0 /
15,8*
min/nom/max
Input power (1) kW 3,53 4,38 4,38 4,88
E.E.R. (1) W/W 3,25 3,15 3,15 3,08
Cooling capacity (2)
kW 9,17 / 14,0 / 14,7*
9,20 / 15,8 /
16,6*
9,20 / 15,8 /
16,6*
9,09 / 17,1 /
18,0*
min/nom/max
Input power (2) kW 2,59 3,15 3,15 3,59
E.E.R. (2) W/W 5,40 5,02 5,02 4,76
SEER (5) W/W 4,77 4,94 4,94 5,05
Water ow rate (1) L/s 0,55 0,66 0,66 0,71
User side heat exchanger pressure drops
(1)
kPa 12,9 17,5 17,5 20,6

Heang capacity (3)
kW 7,54 / 14,1 / 15,2*
7,36 / 16,3 /
17,6*
7,36 / 16,3 /
17,6*
7,30 / 17,9 /
19,3*
min/nom/max
Input power(3) kW 2,91 3,49 3,49 4,07
C.O.P. (3) W/W 4,85 4,67 4,67 4,40
Heang capacity (4)
kW 7,23 / 13,6 / 14,6*
7,06 / 15,8 /
17,0*
7,06 / 15,8 /
17,0*
7,02 / 17,3 /
18,7*
min/nom/max
Input power (4) kW 3,55 4,24 4,24 4,92
C.O.P. (4) W/W 3,82 3,72 3,72 3,52
SCOP (6) W/W 4,48 4,50 4,50 4,46
Water ow rate (4) L/s 0,65 0,76 0,76 0,83
User side heat exchanger (4) kPa 13,0 17,6 17,6 21,0
Energy eciency
Classe A+++/A++ A+++/A++ A+++/A++ A+++/A++
water 35°C / 55°C
Compressor
Type Twin Rotary DC Inverter
Number of compressors 1 1 1 1
Refrigerant oil (type) ESTER OIL VG74
Oil charge (amount) L 1,4 1,4 1,4 1,4
Refrigerant circuits 1 1 1 1

Type R32 R32 R32 R32
Refrigerant charge (7) kg 3,2 3,5 3,5 3,5
Amount of refrigerant in equivalent CO2
tonnes (7)
ton 2,2 2,4 2,4 2,4
Design pressure (high/low) heat pump
mode
bar 42,8/1,3 42,8/1,3 42,8/1,3 42,8/1,3
Design pressure (high/low) chiller mode bar 42,8/3,5 42,8/3,5 42,8/3,5 42,8/3,5
Fans
Type DC Brushless Motor
Number 2 2 2 2
Internal heat
exchanger
Internal heat exchanger type Plates
N° internal heat exchangers 1 1 1 1
Water content L 1,7 1,7 1,7 1,7
Water circuit
Useful head (1) kPa 75,0 62,3 62,3 55,6
Water content of hydronic circuit L 3,0 3,0 3,0 3,0
Maximum water side pressure bar 6 6 6 6
Plumbing ngs inch 1"M 1"M 1"M 1"M
Minimum water volume (8) L 60 70 70 70
Maximum circulator output kW 0,14 0,14 0,14 0,14
Maximum circulator absorbed current A 1,10 1,10 1,10 1,10
Energy Eciency Index (EEI) cirulator ≤ 0,23 ≤ 0,23 ≤ 0,23 ≤ 0,23
Noise level
Power sound level Lw (9) dB(A) 68 68 68 68
Power sound level Lw (10) dB(A) 66 66 66 66
Electrical data
Power supply
400V/3P+N+T/50Hz
230V/1/50Hz
400V/3P+N+T/50Hz
400V/3P+N+T/50Hz
Maximum input power kW 6,6 7,0 7,0 8,3
Maximum input current A 9,5 30,4 10,1 12,0
Maximum input power with anfreezre kit kW 6,7 7,1 7,1 8,5
Maximum input current with anfreeze kit A 9,7 31,0 10,3 12,2
