Trane Precedent YZC072F User Manual

Dimensions and Weights
RT-SVX46G-EN 21
Figure 27. Cooling and gas/electric - 6 to 10 tons ultra
high efficiency - duct connections field
fabricated
Note: All dimensions are in inches/millimeters.
Figure 28. Cooling and gas/electric - 6 to 8.5 tons ultra
high efficiency - power exhaust
Note: All dimensions are in inches/millimeters.
ALL FLANGES 1 1/4" (31 MM)
17 3/4”
451MM
17 3/4”
451MM
33 3/4”
857 MM
33 3/4”
857 MM
RETURN
SUPPLY
6 11/16”
170 MM
16 1/2”
419 MM
Figure 29. Cooling and gas/electric - 6 to 8.5 tons ultra
high efficiency - swing diameter for hinged
door(s) option
Note: All dimensions are in inches/millimeters.
Figure 30. Cooling and gas/electric - 6 to 10 tons ultra
high efficiency - economizer, manual or
motorized fresh air damper
Note: All dimensions are in inches/millimeters.
21 3/8”
543 MM
17”
432 MM
34 5/8”
879 MM
Applicable to
Y_C models only
BAROMETRIC RELIEF HOODBAROMETRIC RELIEF HOOD
ECONOMIZER HOODECONOMIZER HOOD
Dimensions extends to 21 5/8"/549 MMDimensions extends to 21 5/8"/549 MM
when powered exhaust is coupledwhen powered exhaust is coupled
with low leak economizerwith low leak economizer
7 3/4”7 3/4”
198 MM198 MM
12”12”
304 MM304 MM
16 3/4”16 3/4”
425 MM425 MM
6 7/8”6 7/8”
175 MM175 MM
