56 RT-SVX46G-EN
Unit Wiring Diagrams Numbers
Note: Wiring diagrams can be accessed using e-Library
by entering the diagram number in the literature
order number search field or by contacting
technical support.
Table 14. Unit wiring diagram numbers
Schematic Type Drawing Number Description
Control ReliaTel™
230,460,575V 1213-1929 Diagram Controls; YZC(072,090,102,120)F(3,4,W)
230, 460V 4366-8324 Diagram Controls; YZC(036E, 048F, 060E4)
230, 460V 1213-1655 Diagram Control; YZC060E3
230, 460V 1213-3641
Ultra Low NOx, 3, 4 and 5 Ton,
208-230/60/3, 460/60/3, YZC (036E, 048F)3,4, (060E)4
UH
E VSC
23
0 1213-3642
Ultra Low NOx, 5 TON, 208-230/60/3,
YZC060E3, Ultra High EFF VSC
Power ReliaTel™
230V 1213-1924 Diagram Power; YZC(072,090,102,120)F3
460V 1213-1925 Diagram Power; YZC(072,090,102,120)F4
575V 1213-1927 Diagram Power; YZC(072,090,102,120)FW
460V 4366-8316 Diagram Power; YZC(036E, 048F, 060E)4
230V 4366-8318 Diagram Power; YZC(036E, 048F)3
230V 1213-1654 Diagram Power; YZC060E3
460V 1213-3643
Ultra Low NOx, 3, 4 and 5 Ton, 460/60/3,
YZC(036E-048F-060E)4, Ultra High EFF VSC
230V 1213-3646
Ultra Low NOx, 5 Ton, 208-230/60/3,
YZC060E3, Ultra High EFF VSC
230V 1213-3647
Ultra Low NOx, 3 and 4 Ton, 208-230/60/3,
YZC(036E-048F)3, Ultra High EFF VSC
Connection ReliaTel™
230V 1213-2072 Diagram Connection; YZC(072,090,102,120)F3
460, 575V 1213-2074 Diagram Connection; YZC(072,090,102,120)F4,W
230V 4366-8508 Diagram Connection; YZC036E3
460V 4366-8509 Diagram Connection; YZC036E4
230V 4366-8510 Diagram Connection; YZC048F3
230V 4366-8968 Diagram Connection; YZC048F3
460V 4366-8511 Diagram Connection; YZC(048F4,060E4)
230V 1213-3700 Ultra Low NOx, 3 Ton, UHE VSC
460V 1213-3701 Ultra Low NOx, 3 Ton, UHE VSC
230V 1213-3702 Ultra Low NOx, 4 Ton, UHE VSC
460V 1213-3703 Ultra Low NOx, 4 and 5 Ton, UHE VSC
230V 1213-3704 Ultra Low NOx, 5 Ton, UHE VSC
