Trane Precedent - Page 21

21RT-PRC006-EN
Table GD-4 — General Data
10 Ton Convertible
YSC120A3, A4, AW, AK
Cooling Performance
1
Gross Cooling Capacity 118,000
EER
2
10.2
8
Nominal CFM / ARI Rated CFM 4,000/3,200
ARI Net Cooling Capacity 114,000
8
Integrated Part Load Value
3
11. 3
8
System Power (KW) 11.18
8
Heating Performance
4
Heating Models Low Medium
10
High
Heating Input (Btu) 150,000 200,000 250,000
Heating Output (Btu) 121,500 162,000 202,500
AFUE%
5
81 81 81
Steady State Efficiency (%) 81 81 81
No. Burners 3 4 5
No. Stages 2 2 2
Gas Supply Line Pressure
Natural (minimum/maximum) 4.5/14.0
LP (minimum/maximum) 10.0/14.0
Gas Connection Pipe Size (in.) 3/4 3/4 3/4
Compressor
No./Type 2/Scrolls
Outdoor Sound Rating (dB)
6
86
Outdoor Coil - Type Lanced
Tube Size (in.) OD 0.3125
Face Area (sq ft) 19.83
Rows/FPI 2/17
Indoor Coil - Type Lanced
Tube Size (in.) 0.3125 .
Face Area (sq ft) 12.36
Rows/FPI 4/16
Refrigerant Control Short Orifice
Drain Connection No./Size (in.) 1¾NPT
(10 Tons)
Standard Efficiency
General
Data
