RT-PRC006-EN80

Electrical

Data (High Efficiency)

Table ED-2 — Unit Wiring - High Efficiency

Standard Indoor Fan Motor Oversize Indoor Fan Motor Belt Drive Indoor Fan Motor

Unit Minimum Maximum Fuse Minimum Maximum Fuse Minimum Maximum Fuse

Unit Operating Circuit Size or Maximum Circuit Size or Maximum Circuit Size or Maximum

Tons Model No. Voltage Range Ampacity Circuit Breaker

Ampacity Circuit Breaker

YHC036A1 187-253 23.9 40 26.3 40 — —

3 YHC036A3 187-253 17.2 25 19.6 30 19.9 30

YHC036A4 414-506 9.0 15 10.2 15 10.4 15

YHC036AW 517-633 7.1 15 7.7 15 7.7 15

YHC048A1 187-253 29.4 45 31.5 50 — —

YHC048A3 187-253 21.2 30 23.3 35 22.6 35

4 YHC048A4 414-506 11.0 15 12.6 15 11.8 15

YHC048AW 517-633 8.3 15 9.1 15 8.5 15

YHC060A1 187-253 39.5 60 41.2 60 — —

YHC060A3 187-253 30.0 45 31.7 45 28.8 45

5 YHC060A4 414-506 14.7 20 15.0 20 14.3 20

YHC060AW 517-633 11.8 15 12.4 15 11.4 15

YHC072A3 187-253 34.8 50 36.1 50 — —

6 YHC072A4 414-506 17.5 25 18.1 25 — —

YHC072AW 517-633 13.5 20 14.3 20 — —

YHC092A3 187-253 38.1 50 41.2 50 — —

7½ YHC092A4 414-506 19.4 25 20.9 25 — —

YHC092AW 517-633 14.8 15 16.0 20 — —

YHC102A3 187-253 42.3 50 45.4 60 — —

8½ YHC102A4 414-506 21.4 25 22.9 30 — —

YHC102AW 517-633 16.6 20 17.8 20 — —

YHC120A3 187-253 48.6 60 52.6 60 — —

10 YHC120A4 414-506 25.3 30 27.3 35 — —

YHC120AW 517-633 19.9 25 21.6 25 — —

Notes:

1. HACR breaker per NEC.
