Trane Precedent User Manual

39RT-PRC006-EN
Performance
Data
(3 Ton)
Standard Efficiency
For Standard Evaporator Fan Speed (RPM), reference Table PD-86.
Notes:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-89 to determine additional static pressure drop due to
other options/accessories
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.
1. Field Supplied Fan Sheave AK69 required. Field Supplied Belt may be
necessary.
2. Field Supplied Fan Sheave AK41 required. Field Supplied Belt may be
necessary.
Factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and
continuously at all cataloged conditions. Using the full horsepower range
of our fan motors as shown in our tabular data will not result in nuisance
tripping or premature motor failure. Our product’s warranty will not be
affected.
Table PD-21— Belt Drive Evaporator Fan Performance — 3 Ton — YSC036A3,A4,AW*H — High Heat —Downflow Airflow
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1-HP Standard Motor & Field Supplied Low Static Drive (1) 1-HP Standard Motor & Drive
960 503 0.11 578 0.15 641 0.19 696 0.23 747 0.27 796 0.32 841 0.36 884 0.42 926 0.47 966 0.52
1080 548 0.15 616 0.19 678 0.23 731 0.28 780 0.32 826 0.37 870 0.42 912 0.47 952 0.53 991 0.59
1200 593 0.19 657 0.23 716 0.28 768 0.33 815 0.38 859 0.43 901 0.49 942 0.54 980 0.60 1017 0.66
1320 640 0.24 698 0.29 754 0.34 806 0.40 852 0.45 895 0.51 935 0.56 974 0.62 1012 0.68 1048 0.74
1440 688 0.31 742 0.35 794 0.41 844 0.47 890 0.53 931 0.59 970 0.65 1009 0.71 1045 0.77 1080 0.84
Table PD-22 — Continued
External Static Pressure (Inches of Water)
1.10 1.20 1.30 1.40 1.50
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1-HP Standard Motor & Drive
960 1005 0.58 1041 0.64 1076 0.70 1110 0.76 1142 0.82
1080 1029 0.65 1064 0.71 1099 0.77 1133 0.83 1166 0.90
1200 1053 0.72 1089 0.78 1123 0.85 1156 0.91 1189 0.98
1320 1082 0.80 1116 0.87 1150 0.93 1182 1.00 1214 1.07
1440 1113 0.90 1146 0.97 1178 1.04 1209 1.11 1240 1.18
1-HP Standard Motor &
Field Supplied High Static Drive (2)
For Standard Evaporator Fan Speed (RPM), reference Table PD-86.
Notes:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-89 to determine additional static pressure drop due to other
options/accessories
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.
1. Field Supplied Fan Sheave AK69 required. Field Supplied Belt may be
necessary.
2. Field Supplied Fan Sheave AK41 required. Field Supplied Belt may be necessary.
Factory supplied motors, in commercial equipment, are definite purpose motors,
specifically designed and tested to operate reliably and continuously at all cataloged
conditions. Using the full horsepower range of our fan motors as shown in our
tabular data will not result in nuisance tripping or premature motor failure. Our
product’s warranty will not be affected.
Table PD-20 — Belt Drive Evaporator Fan Performance — 3 Ton — YSC036A3,A4,AW*L, M — Low and Medium Heat —Downflow Airflow
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1-HP Standard Motor & Field Supplied Low Static Drive (1) 1-HP Standard Motor & Drive
960 — — 570 0.14 634 0.18 690 0.22 741 0.27 791 0.31 836 0.36 879 0.41 922 0.46 961 0.52
1080 537 0.14 606 0.18 669 0.23 724 0.27 773 0.32 819 0.36 864 0.41 906 0.47 946 0.52 985 0.58
1200 581 0.18 645 0.22 705 0.27 759 0.33 807 0.38 851 0.42 894 0.48 935 0.53 973 0.59 1011 0.65
1320 627 0.23 686 0.28 742 0.33 795 0.39 842 0.44 885 0.50 927 0.55 966 0.61 1003 0.67 1040 0.73
1440 673 0.29 728 0.34 780 0.39 831 0.45 878 0.52 921 0.58 960 0.64 998 0.69 1034 0.76 1070 0.82
Table PD-20 — Continued
External Static Pressure (Inches of Water)
1.10 1.20 1.30 1.40 1.50
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1-HP Standard Motor & Drive
960 1000 0.57 1037 0.63 1072 0.69 1106 0.75 1139 0.81
1080 1022 0.64 1058 0.70 1093 0.76 1127 0.82 1161 0.89
1200 1047 0.71 1083 0.77 1117 0.83 1150 0.90 1183 0.97
1320 1075 0.79 1108 0.85 1141 0.92 1174 0.99 1206 1.06
1440 1104 0.88 1137 0.95 1170 1.02 1201 1.09 1231 1.16
1-HP Standard Motor & Field Supplied High Static Drive (2)

Trane Precedent Specifications

General

Refrigerant	R-410A
Type	Packaged
Stages	Single
Voltage	208/230V or 460V
Heating Options	Electric or Gas
