Trane Precedent User Manual

RT-PRC006-EN42
Performance
Data
(4 Ton)
Standard Efficiency
For Standard Evaporator Fan Speed (RPM), reference Table PD-86.
Notes:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-89 to determine additional static pressure drop
due to other options/accessories
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.
1. Field Supplied Fan Sheave AK61 required. Field Supplied
Belt may be necessary.
2. Field Supplied Fan Sheave AK41 required. Field Supplied
Belt may be necessary.
Factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and
continuously at all cataloged conditions. Using the full horsepower range of
our fan motors as shown in our tabular data will not result in nuisance
tripping or premature motor failure. Our product’s warranty will not be
affected.
Table PD-27 — Belt Drive Evaporator Fan Performance — 4 Ton — YSC048A3,A4,AW*H — High Heat — Horizontal Airflow
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive
Low Static Drive (1)
1280 686 0.27 758 0.33 817 0.39 871 0.45 922 0.51 968 0.58 1013 0.64 1053 0.72 1091 0.79 1127 0.86
1440 753 0.36 821 0.43 878 0.50 930 0.57 977 0.63 1022 0.70 1066 0.78 1107 0.85 1145 0.93 1180 1.01
1600 821 0.48 884 0.55 941 0.63 990 0.70 1035 0.78 1078 0.86 1120 0.93 1160 1.02 1197 1.10 1234 1.18
1760 891 0.62 949 0.70 1004 0.78 1052 0.87 1096 0.95 1137 1.03 1176 1.12 1214 1.20 1251 1.29 1287 1.38
1920 962 0.78 1015 0.87 1067 0.97 1115 1.06 1158 1.15 1198 1.24 1235 1.33 1271 1.42 — — — —
1-HP Standard Motor & Field SuppliedHigh Static Drive (2)
Table PD-27 — Continued
External Static Pressure (Inches of Water)
1.10 1.20 1.30 1.40 1.50
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1-HP Standard Motor & Drive
1280 1160 0.94 1194 1.01 1224 1.08 1254 1.15 1283 1.22
1440 1214 1.09 1247 1.18 1278 1.26 1308 1.34 1338 1.43
1600 1268 1.26 1300 1.35 1331 1.44 — — — —
1760 1321 1.47 — — — — — — — —
1920 —— —— —— —— ——
1-HP Standard Motor & Field Supplied High Static Drive (2)
Table PD-26 — Belt Drive Evaporator Fan Performance — 4 Ton — YSC048A3,A4,AW*L, M — Low and Medium Heat — Horizontal Airflow
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1-HP Standard Motor & Field Supplied 1-HP Standard Motor & Drive
Low Static Drive (1)
1280 669 0.25 744 0.31 805 0.37 860 0.44 911 0.50 959 0.56 1003 0.63 1045 0.70 1082 0.77 1119 0.85
1440 733 0.34 803 0.41 864 0.48 916 0.55 965 0.62 1011 0.69 1055 0.76 1096 0.83 1134 0.91 1171 0.99
1600 800 0.45 864 0.53 923 0.60 974 0.68 1021 0.75 1064 0.83 1106 0.91 1147 0.99 1185 1.07 1221 1.15
1760 868 0.58 926 0.67 982 0.75 1033 0.83 1079 0.92 1121 1.00 1161 1.08 1199 1.17 1237 1.26 1273 1.35
1920 937 0.74 989 0.83 1042 0.92 1092 1.01 1138 1.10 1179 1.19 1217 1.28 1254 1.38 1290 1.47 — —
1-HP Standard Motor & Field Supplied High Static Drive (2)
For Standard Evaporator Fan Speed (RPM), reference Table PD-86.
Notes:
Data includes pressure drop due to standard filters and wet coils.
No accessories or options are included in pressure drop data.
Refer to Table PD-89 to determine additional static pressure drop
due to other options/accessories
Fan Motor Heat (MBH) = 2.829 x Fan BHP+.4024.
1. Field Supplied Fan Sheave AK61 required. Field Supplied Belt
may be necessary.
2. Field Supplied Fan Sheave AK41 required. Field Supplied Belt
may be necessary.
Factory supplied motors, in commercial equipment, are definite purpose motors,
specifically designed and tested to operate reliably and continuously at all cataloged
conditions. Using the full horsepower range of our fan motors as shown in our
tabular data will not result in nuisance tripping or premature motor failure. Our
product’s warranty will not be affected.
Table PD-26 — Continued
External Static Pressure (Inches of Water)
1.10 1.20 1.30 1.40 1.50
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1-HP Standard Motor & Drive
1280 1154 0.92 1187 1.00 1218 1.07 1248 1.14 1277 1.21
1440 1205 1.07 1237 1.15 1270 1.24 1300 1.32 1330 1.40
1600 1256 1.23 1290 1.33 1322 1.42 — — — —
1760 1307 1.43 — — — — — — — —
1920 —— —— —— —— ——
1-HP Standard Motor & Field Supplied High Static Drive (2)

Trane Precedent Specifications

General

Refrigerant	R-410A
Type	Packaged
Stages	Single
Voltage	208/230V or 460V
Heating Options	Electric or Gas
