Trane Precedent User Manual

RT-PRC006-EN82
Electrical
Data (Standard Efficiency)
Table ED-5 — Electrical Characteristics — Compressor Motor And Condenser Motor — Standard Efficiency
Compressor Motor Condenser Fan Motors
Unit Amps Amps
Tons Model No. No. Volts Phase HP
2
RPM RLA LRA No. Phase HP FLA LRA
YSC036A1 1 208-230 1 3.1 3450 17.2 104.0 1 1 .20 1.5 2.5
3 YSC036A3 1 208-230 3 3.1 3450 11.3 74.0 1 1 .20 1.5 2.5
YSC036A4 1 460 3 3.1 3450 6.0 37.6 1 1 .20 0.6 1.3
YSC036AW 1 575 3 3.1 3450 4.9 30.4 1 1 .20 0.5 1.2
YSC048A1 1 208-230 1 3.9 3450 22.7 131.0 1 1 .33 2.0 6.6
YSC048A3 1 208-230 3 3.9 3450 14.6 91.0 1 1 .33 2.0 6.6
4
YSC048A4 1 460 3 3.9 3450 7.9 46.0 1 1 .33 1.2 2.5
YSC048AW 1 575 3 3.9 3450 6.1 37.0 1 1 .33 0.7 1.5
YSC060A1 1 208-230 1 5.1 3450 31.3 144.0 1 1 .33 2.0 6.6
YSC060A3 1 208-230 3 5.1 3450 18.6 128.0 1 1 .33 2.0 6.6
5
YSC060A4 1 460 3 5.1 3450 9.5 63.0 1 1 .33 1.2 2.5
YSC060AW 1 575 3 5.1 3450 7.5 49.0 1 1 .33 0.7 1.5
YSC060AK 1 380 3 5.1 3450 11.4 64 1 1 .40 1.1 4.3
YSC072A3 1 208-230 3 6 3450 19.0 156 1 1 .70 3.85 9.30
6 YSC072A4 1 460 3 6 3450 10.1 75 1 1 .70 2.50 5.80
YSC072AW 1 575 3 6 3450 7.7 54 1 1 .70 1.54 3.60
YSC072AK 1 380 3 6 3450 12.2 70 1 1 .75 2.5 7.7
YSC090A3 1 208-230 3 7.5 3450 26.0 181.5 1 1 .70 3.85 9.30
YSC090A4 1 460 3 7.5 3450 13.6 95.0 1 1 .70 2.50 5.80
YSC090AW 1 575 3 7.5 3450 10.9 69.0 1 1 .70 1.54 3.60
YSC090AK 1 380 3 7.5 3450 16.4 106.3 1 1 .75 2.5 7.7
7½ YSC092A3 2 208-230 3 4/2.8 3450 14.7/10.3 91/77 1 1 .70 3.85 9.30
YSC092A4 2 460 3 4/2.8 3450 7.6/5.4 50/39 1 1 .70 2.50 5.80
YSC092AW 2 575 3 4/2.8 3450 5.8/4.2 37/31 1 1 .70 1.54 3.60
YSC102A3 2 208-230 3 5.1/2.8 3450 18.6/10.3 128/77 1 1 .75 4.0 9.4
8½ YSC102A4 2 460 3 5.1/2.8 3450 10.0/5.4 63/39 1 1 .75 2.8 6.8
YSC102AW 2 575 3 5.1/2.8 3450 8.2/4.2 49/31 1 1 .75 2.4 6.2
YSC102AK 1 380 3 5.1/2.8 3450 12.1/6.6 64/39 1 1 7.5 2.5 7.7
YSC120A3 2 208-230 3 5.1/3.9 3450 18.6/14.7 128/91 1 1 .75 4.0 9.4
10 YSC120A4 2 460 3 5.1/3.9 3450 9.5/7.4 63/46 1 1 .75 2.8 6.8
YSC120AW 2 575 3 5.1/3.9 3450 7.8/5.8 49/37 1 1 .75 2.4 6.2
YSC120AK 1 380 3 5.1/3.9 3450 11.5/9.0 64/54 1 1 .75 2.5 7.7

Trane Precedent Specifications

General

Refrigerant	R-410A
Type	Packaged
Stages	Single
Voltage	208/230V or 460V
Heating Options	Electric or Gas
