Periodic Maintenance
RTAA Operator's Log
Job Name: Job Location:
Unit Serial Number: Elevation Above Sea Level:
Model No: Nameplate Voltage:
Compressor A Serial Number: Fan Motor RLA
Compressor A Model Number: Heat Tape Voltage
Compressor B Serial Number:
Compressor B Model Number:
Evap Water Pressure Drop
Design PSID: Actual PSID:
Design GPM: Actual GPM:
Circuit 1 2 1 2 1 2
Compressor A B A B A B
15 min 15 min 30 min 30 min 45 min 45 min
Unit Phase A-B
Voltage A-C
B-C
Compressor Phase A
Amps B
C
Unit Operating Mode
Last Diagnostic
Evaporator Entering Water Temp.
F or C
Evaporator Leaving Water Temp.
F or C
Outdoor Air Temperature F or C
Active Chill Water Setpoint
F or C
Active Current Limit Setpoint
Saturated Evaporator Rfgt.Temp.
F or C
Saturated Condenser Rfgt. Temp. F or C
Condenser Refrigerant Pressure
psig/kPa
Evaporator Refrigerant Pressure psig/kPa
Compressor RLA % RLA
Compressor Starts
Compressor Hours
External Hardwired Lockout Not Locked out/ Locked out Not Locked out/ Locked out
Front Panel Lockout Not Locked out/ Locked out Not Locked out/ Locked out
