98
RTAA-IOM-3
Figure 53
Condition/Diagnostic Codes
UNIT OPERATING STATUS COMPRESSOR OPERATING STATUS
CODE DESCRIPTION CODE DESCRIPTION
Blank UCM Power Off 00 Compressor Stop
888888.8 UCM Paw Up 16 Compressor Lockout
00 Unit Stop 17 Cprsr Service Pumpdown
01 Auto-Local 70 Cprsr Restart Inhibit
02 Auto-Remote 72 Cprsr Start
17 Service Pumpdown 74 Run Normal
70 Unit Restart Inhibit 75 Run: Current Limit
72 Unit Start 76 Run: Condenser Limit
74 Run:Normal 77 Run: Evaporator Limit
75 Run:Current Limit 7E Run:Unload
78 Run:Condenser Limit
77 Run:Evaporator Limit
7E Run:Unload
88 Reset
DIAGNOSTIC TYPES
100 External Unit Stop
101 Ice Building Complete MMR Machine Shutdown-Manual Reset
118 EXV Test CMR Circuit Shutdown-Man Reset
174 Ice Building; Normal MAR Machine Shutdown-Auto Reset
175 Ice Building: Current Limit CAR Circuit Shutdown-Auto Reset
176 Ice Building: Condenser Limit IFW Informational-Warning
177 Ice Building: Evaporator Limit
200 Low Ambient Run Inhibit
UNIT DIAGNOSTICS CONDITION
FLASHING DISPLAY: MEANS:
A xxx A
New CMR, CAR. or IFW Diagnostic Exists.
A xxx ↔ C yyy Operating Code when MMR or MAR occurred. Diagnostic currently inhibiting operation.
b yyy Manual reset required to restore full operation. This or other latching diagnostics exist.
C yyy Condition creating MAR, CAR or IFW still exists. If MMR or CMR, manual reset required.
10 uu The chilled water setpoint is too close to a cutout setpoint.
DASHES: MEANS:
d ---- The chiller is in either ice bldg or ice bldg compl; Ivg chld wtr stpt is not applicable.
33 ---- The chiller is in normal cooling; the active ice termination setpoint is not applicable.
Other (e.g. 14----) Option either not installed or not enabled.
CODE DESCRIPTION TYPE CODE DESCRIPTION TYPE
87 Chock External Chilled Water Stpt IFW 19F Phase Loss - Cprsr D CMR
89 Check External Current Limit Stpt IFW 1AO Power Loss - Cprsr A CAR
8A Chilled Water Flow (Ent Wtr Temp) MMR 1A1 Power Loss - Cprsr 8 CAR
8E Evap Entering Water Temp Sensor MMR 1A2 Power Loss - Cprsr C CAR
8F Cond Rfgt Tamp Sensor - Ckt I CMR 1A3 Power Loss - Cprsr D CAR
90 Cond Rfgt Temp Sensor - Ckt 2 CMR 1A4 Remote communications Loss IFW
93 Evap Rfgt Temp Sensor - Ckt I CMR 1A5 Oil Flow Control - Cprsr A CMR
94 Evap Rfgt Tamp Sensor - Ckt 2 CMR 1A6 Oil Flow Control - Cprsr B CMR
A0 Zone Temp Sensor IFW 1A7 Oil Flow Control - Cprsr C CMR
A1 Outdoor Air Temp Sensor IFW 1A8 Oil Flow Control - Cprsr D CMR
Ab Evap Leaving Wtr Temp Sensor MMR 1A9 EXV Elec Drive Ckt - Rfgt Ckt I CMR
bA Overload Trip - Cprsr A CMR 1AA EXV Elec Drive Ckt - Rfgt Ckt 2 CMR
bb Overload Trip - Cprsr 0 CMR 1Ad Memory Error Type I (See Oper Manual) IFW
bC Overload Trip - Cprsr C CMR 1AE Low Differential Press - Ckt I CMR
bd Overload Trip - Cprsr D CMR 1AF Low Differential Press - Ckt 2 CMR
bE High Pressure Cutout - Cprsr C CMR 1b2 Severe Phase Unbalance - Cprsr A CMR
bF High Pressure Cutout - Cprsr D CMR 1b3 Severe Phase Unbalance - Cprsr B CMR
C5 Low Chilled Water Temp (Unit off) IFW 1b4 Severe Phase Unbalance - Cprsr C CMR
C6 Low Chilled Water Temp (Unit on) MAR 1b5 Severs Phase Unbalance - Cprsr 0 CMR
CA Contactor - Cprsr A MMR 1b6 Compressor Overload Setting - Cprsr A IFW
Cb Contactor - Cprsr B MMR 1b7 Compressor Over load Setting - Cprsr B IFW
cc Contactor - Cprsr C MMR 1b8 Compressor Overload Setting - Cprsr C IFW
Cd Contactor - Cprsr D MMR 1b9 Compressor Overload Setting - Cprsr D IFW
d7 Over Voltage MAR 1bA Phase Unbalance - Cprsr A CMR
d8 Under Voltage MAR 1bb Phase Unbalance - Cprsr 8 CMR
Ed Chilled Water Flow Interlock MAR 1bC Phase Unbalance - Cprsr C CMR
F5 High Pressure Cutout - Cprsr A CMR 1bd Phase Unbalance - Cprsr D CMR
F6 High Pressure Cutout - Cprsr B CMR 1bE Winding Temp. - Cprsr A CMR
Fd Emergency Stop Input MMR 1bF Winding Temp. - Cprsr B CMR
180 Starter Transition - Cprsr A CMR 1C0 Winding Temp. - Cprsr C CMR
181 Starter Transition - Cprsr B CMR 1C1 Winding Temp. - Cprsr D CMR
182 Starter Transition - Cprsr C CMR 1C2 Discharge Temp. - Cprsr A CMR
183 Starter Transition - Cprsr D CMR 1C3 Discharge Temp. - Cprsr 8 CMR
184 Phase Reversal - Cprsr A CMR 1C4 Discharge Temp. - Cprsr C CMR
185 Phase Reversal - Cprsr 8 CMR 1C5 Discharge Temp. - Cprsr D CMR
186 Phase Reversal - Cprsr C CMR 1C6 High Differential Pressure - Ckt I CMR
187 Phase Reversal - Cprsr D CMR 1C7 High Differential Pressure - Ckt 2 CMR
190 Low Superheat - Ckt I CMR 1d1 Memory Error Type 11 (See Oper Manual) IFW
191 Low Superheat - Ckt 2 CMR 1d2 Memory Error Type III (See Oper Manual) IFW
194 Low Evap Rfgt Tamp - Ckt I CMR 1d3 Cprsr Suction Temp. Sensor - Ckt 1 CMR
195 Low Evap Rfgt Temp - Ckt 2 CMR 1d4 Cprsr Suction Temp. Sensor - Ckt 2 CMR
198 Low Oil I Flow - Cprsr A CMR 1d7 Phase Reversal Prot. Lost - Cprsr A CMR
199 Low 01 1 Flow - Cprsr B CMR 1d8 Phase Reversal Prot. Lost - Cprsr B CMR
19A Low Oil Flow - Cprsr C CMR 1d9 Phase Reversal Prot. Lost - Cprsr C CMR
19b Low Oil Flow - Cprsr D CMR 1dA Phase Reversal Prot. Lost - Cprsr D CMR
19C Phase Loss - Cprsr A CMR 1db Slave-Exv Elec Drive Ckt - Rfgt Ckt 1 CMR
19d Phase Lose - Cprsr B CMR 1dc Slave-Exv Elec Drive Ckt - Rfgt Ckt 2 CMR
19E Phase Loss - Cprsr C CMR 4xy See Operator’s Manual – – –
X3956048201 Rev. B
