12 RTAD-SVX01F-E4
General Information
English Units
Table 9 - General Data RTAD Standard
Size 085 100 115 125 145 150 165 180
Compressor Quantity 22222222
Nominal Size (1) (Tons) 40/40 50/50 60/60 70/70 85/70 85/85 100/85 100/100
Evaporator
Evaporator Model EG120 EG140 EG170 EG200 EG200 EG200 EG250 EG250
Water Storage (Gallon) 28.0 71.3 58.7 53.9 53.9 53.9 109.6 109.6
Minimum Flow (GPM) 65.2 95.1 115.0 139.2 139.2 139.2 184.0 184.0
Maximum Flow (GPM) 274.6 329.9 393.1 486.4 486.4 486.4 603.0 603.0
Condenser
Qty of Coils 22222222
Coil Length (inch) 108 144 144 144 180 180 216 216
Coil Height (inch) 64 64 64 64 64 64 64 64
Fin series (Fins/ft) 192 192 192 192 192 192 192 192
Number of Rows 3/3 2/2 3/3 3/3 3/3 3/3 3/3 3/3
Condenser Fans
Quantity (1) 3/3 3/3 3/3 3/3 5/4 5/5 6/5 6/6
Diameter (inch) 30 30 30 30 30 30 30 30
Total Air Flow (CFM) 49556 60460 57194 57248 78439 82716 95103 99250
Nominal RPM 915 915 915 915 915 915 915 915
Tip Speed (Ft/s) 119.8 119.8 119.8 119.8 119.8 119.8 119.8 119.8
Motor kW (kW) 2.05 2.05 2.05 2.05 2.05 2.05 2.05 2.05
Min Starting/Oper Ambient (2)
Standard Unit (°F) 32 32 32 32 32 32 32 32
Low Ambient Unit (°F) 00000000
General Unit
Refrigerant HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a
22222222
% Min. Load (3) 17 17 17 17 17 17 17 17
Refrigerant Charge (1) (lbs.) 52.9/52.9 66.1/70.5 77.2/79.4 79.4/81.6 97/105.8 97/105.8 134.5/130.1 134.5/134.5
Oil Charge (1) (Gallon) 1.59/1.59 1.85/1.85 2.38/2.38 2.64/2.64 2.64/2.64 2.64/2.64 3.96/2.91 3.96/3.96
Operating Weight (4) (lbs.) 5864 6845 7837 7871 9392 9965 11993 12181
Shipping Weight (4) (lbs.) 5631 6257 7348 7425 8944 9517 11074 11261
Table 10 - General Data RTAD High Efficiency
Size 085 100 115 125 145 150
Compressor Quantity 222222
Nominal Size (1) (Tons) 40/40 50/50 60/60 70/70 85/70 85/85
Evaporator
Evaporator Model EG140 EG170 EG200 EG200 EG250 EG250
Water Storage (Gallon) 71.3 58.7 53.9 53.9 109.6 109.6
Minimum Flow (GPM) 95.1 115.0 139.2 139.2 184.0 184.0
Maximum Flow (GPM) 329.9 393.1 486.4 486.4 603.0 603.0
Condenser
Qty of Coils 222222
Coil Length (inch) 144 144 180 180 216 216
Coil Height (inch) 64 64 64 64 64 64
Fin series (Fins/ft) 192 192 192 192 192 192
Number of Rows 3/3 3/3 3/3 3/3 3/3 3/3
Condenser Fans
Quantity (1) 3/3 4/4 4/4 5/5 6/5 6/6
Diameter (inch) 30 30 30 30 30 30
Total Air Flow (CFM) 57108 66046 74100 82628 95008 99132
Nominal RPM 915 915 915 915 915 915
Tip Speed (Ft/s) 119.8 119.8 119.8 119.8 119.8 119.8
Motor kW (kW) 2.05 2.05 2.05 2.05 2.05 2.05
Min Starting/Oper Ambient (2)
Standard Unit (°F) 32 32 32 32 32 32
Low Ambient Unit (°F) 000000
General Unit
Refrigerant HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a
222222
% Min. Load (3) 17 17 17 17 17 17
Refrigerant Charge (1) (lbs.) 70.5/75.0 77.2/79.4 92.6/99.2 92.6/99.2 130.1/134.5 130.1/134.5
Oil Charge (1) (Gallon) 1.59/1.59 1.85/1.85 2.64/2.64 2.64/2.64 2.91/2.91 2.91/2.91
Operating Weight (4) (lbs.) 7143 7430 8609 8818 11883 12004
Shipping Weight (4) (lbs.) 6554 6940 8162 8371 10964 11085
Notes:
(1) Data containing information on two circuits shown as follows: ckt1/ckt2
(2) Minimum start-up/operation ambient based on a 2.22 m/s (5mph) wind across the condenser.
(3) Percent minimum load is for total machine at 10°C (50F) ambient and 7°C (44F) leaving chilled water temp. Not each individual circuit
(4) Weights with aluminium fins, power disconnect switch, isolators and pressure gauges
No. Of independent
Refrigerant Circuits
No. Of independent
Refrigerant Circuits
