RTAD-SVX01F-E4 13
General Information
Table 11 - General Data RTAD Standard Low Noise
Size 085 100 115 125 145 150 165 180
Compressor Quantity 22222222
Nominal Size (1) (Tons) 40/40 50/50 60/60 70/70 85/70 85/85 100/85 100/100
Evaporator
Evaporator Model EG120 EG140 EG170 EG200 EG200 EG200 EG250 EG250
Water Storage (Gallon) 28.0 71.3 58.7 53.9 53.9 53.9 109.6 109.6
Minimum Flow (GPM) 65.2 95.1 115.0 139.2 139.2 139.2 184.0 184.0
Maximum Flow (GPM) 274.6 329.9 393.1 486.4 486.4 486.4 603.0 603.0
Condenser
Qty of Coils 22222222
Coil Length (inch) 108 144 144 144 180 180 216 216
Coil Height (inch) 64 64 64 64 64 64 64 64
Fin series (Fins/ft) 192 192 192 192 192 192 192 192
Number of Rows 3/3 2/2 3/3 3/3 3/3 3/3 3/3 3/3
Condenser Fans
Quantity (1) 3/3 3/3 3/3 3/3 5/4 5/5 6/5 6/6
Diameter (inch) 30 30 30 30 30 30 30 30
Total Air Flow (CFM) 38246 47434 44514 44568 60751 63878 73628 76644
Nominal RPM 730 730 730 730 730 730 730 730
Tip Speed (Ft/s) 95.6 95.6 95.6 95.6 95.6 95.6 95.6 95.6
Motor kW (kW) 1.3 1.3 1.3 1.3 1.3 1.3 1.3 1.3
Min Starting/Oper Ambient (2)
Standard Unit (°F) 32 32 32 32 32 32 32 32
Low Ambient Unit (°F) 00000000
General Unit
Refrigerant HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a
22222222
% Min. Load (3) 17 17 17 17 17 17 17 17
Refrigerant Charge (1) (Lbs.) 52.9/52.9 66.1/70.5 77.2/79.4 79.4/81.6 97/105.8 97/105.8 134.5/130.1 134.5/134.5
Oil Charge (1) (Gallon) 1.59/1.59 1.85/1.85 2.38/2.38 2.64/2.64 2.64/2.64 2.64/2.64 3.96/2.91 3.96/3.96
Operating Weight (4) (Lbs.) 6085 7066 8058 8091 9612 10185 12214 12401
Shipping Weight (4) (Lbs.) 5851 6477 7568 7646 9165 9738 11294 11482
Table 12 - General Data RTAD High Efficiency Low Noise
Size 085 100 115 125 145 150
Compressor Quantity 222222
Nominal Size (1) (Tons) 40/40 50/50 60/60 70/70 85/70 85/85
Evaporator
Evaporator Model EG140 EG170 EG200 EG200 EG250 EG250
Water Storage (Gallon) 71.3 58.7 53.9 53.9 109.6 109.6
Minimum Flow (GPM) 95.1 115.0 139.2 139.2 184.0 184.0
Maximum Flow (GPM) 329.9 393.1 486.4 486.4 603.0 603.0
Condenser
Qty of Coils 222222
Coil Length (inch) 144 144 180 180 216 216
Coil Height (inch) 64 64 64 64 64 64
Fin series (Fins/ft) 192 192 192 192 192 192
Number of Rows 3/3 3/3 3/3 3/3 3/3 3/3
Condenser Fans
Quantity (1) 3/3 4/4 4/4 5/5 6/5 6/6
Diameter (inch) 30 30 30 30 30 30
Total Air Flow (CFM) 44426 50964 57562 63784 73521 76510
Nominal RPM 690 690 690 690 690 690
Tip Speed (Ft/s) 90.3 90.3 90.3 90.3 90.3 90.3
Motor kW (kW) 1.3 1.3 1.3 1.3 1.3 1.3
Min Starting/Oper Ambient (2)
Standard Unit (°F) 32 32 32 32 32 32
Low Ambient Unit (°F) 000000
General Unit
Refrigerant HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a
222222
% Min. Load (3) 17 17 17 17 17 17
Refrigerant Charge (1) (Lbs.) 70.5/75.0 77.2/79.4 92.6/99.2 92.6/99.2 130.1/134.5 130.1/134.5
Oil Charge (1) (Gallon) 1.59/1.59 1.85/1.85 2.64/2.64 2.64/2.64 2.91/2.91 2.91/2.91
Operating Weight (4) (Lbs.) 7363 7650 8830 9039 12103 12225
Shipping Weight (4) (Lbs.) 6775 7161 8382 8591 11184 11305
Notes:
(1) Data containing information on two circuits shown as follows: ckt1/ckt2
(2) Minimum start-up/operation ambient based on a 2.22 m/s (5mph) wind across the condenser.
(3) Percent minimum load is for total machine at 10°C (50F) ambient and 7°C (44F) leaving chilled water temp. Not each individual circuit
(4) Weights with aluminium fins, power disconnect switch, isolators and pressure gauges
No. Of independent
Refrigerant Circuits
No. Of independent
Refrigerant Circuits
