20 RTAD-SVX01F-E4
General Information
Table 21 - General Data RTAD Heat Recovery Standard Low Noise
Unit Size 085 100 115 125 145 150 165 180
Number of Compressors 22222222
Nominal Size (1) (Tons) 40/40 50/50 60/60 70/70 85/70 85/85 100/85 100/100
Evaporator
Evaporator Model EG120 EG140 EG170 EG200 EG200 EG200 EG250 EG250
Water Storage (l) 106 269 223 204 204 204 415 415
Minimum Flow (l/s) 4.1 6 7.3 8.8 8.8 8.8 11.6 11.6
Maximum Flow (l/s) 17.3 20.8 24.8 30.7 30.7 30.7 38.0 38.0
Water Connection Type Victaulic
(inch-mm) 6" - 168.3 6" - 168.3 6" - 168.3 6" - 168.3 6" - 168.3 6" - 168.3 6" - 168.3
Heat Recovery Heat-Exchanger
Type Brazed Plates
Water connection type Victaulic
PHR
Connection diameter (inch-mm) 2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3
Water Storage capacity (l) 889911111212
THR
Connection diameter (inch-mm) - 2" - 60.3 2" - 60.3 2" - 60.3
Water Storage capacity (l) - 10 14 14 16 16 19 19
Condenser
Number of Coils 22222222
Fin series (Fins/ft) 192 192 192 192 192 192 192 192
Number of Rows 3/3 2/2 3/3 3/3 3/3 3/3 3/3 3/3
Condenser Fans
Quantity (1) 3/3 3/3 3/3 3/3 5/4 5/5 6/5 6/6
Diameter (mm) 762 762 762 762 762 762 762 762
Total Air Flow (m
3
/s) 18.1 22.4 21.0 21.0 28.7 30.1 34.7 36.2
Nominal Speed (rpm) 750 750 750 750 750 750 750 750
Motor kW (kW) 1.23 1.23 1.23 1.23 1.23 1.23 1.23 1.23
Min Starting/Oper Ambient (2)
PHR (°C)00000000
THR (°C) -18 -18 -18 -18 -18 -18 -18 -18
General Unit
Refrigerant HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a
22222222
% Min. Load (3) 17 17 17 17 17 17 17 17
Weight. Capacities & Dimensions
PHR
Refrigerant Charge (1) (kg) 26/26 33/35 38/39 39/40 47/51 47/51 65/63 65/65
Oil Charge (1) (l) 6/6 7/7 9/9 10/10 10/10 10/10 15/11 15/15
Operating Weight (4) (kg) 2836 3276 3735 3750 4445 4705 5635 5722
Shipping Weight (4) (kg) 2082 2520 2978 2991 3686 3946 4873 4960
THR
Refrigerant Charge (1) (kg) - 55 / 52 67 / 64 68 / 64 86 / 84 86 / 84 100 / 95 100 / 98
Oil Charge (1) (l) - 5 / 4 8 / 7 8 / 7 8 / 7 8 / 7 13 / 7 13 / 12
Operating Weight (4) (kg) - 3447 3933 3948 4715 4975 5906 5991
Shipping Weight (4) (kg) - 3161 3689 3723 4482 4742 5459 5544
Dimensions
Length (mm) 3507 4426 4426 4426 5351 5351 6370 6370
Width (mm) 2260 2260 2260 2260 2260 2260 2260 2260
Height (mm) 2095 2095 2095 2095 2115 2115 2215 2215
(1) Data containing information on two circuits shown as follows: ckt1/ckt2
(2) Minimum start-up/operation ambient based on a 2.22 m/s wind across the condenser.
(3) Percent minimum load is for total machine at 10°C ambient and 7°C leaving chilled water temp. Not each individual circuit.
(4) With aluminum fins
5"1/2 O.D.-
139.7
3" O.D. -
76.1
3" O.D. -
76.1
3" O.D. -
76.1
3" O.D. -
76.1
Water Connection
Diameter
No. Of independent
Refrigerant Circuits
