Table 22 - General Data RTAD Heat Recovery High Efficiency Low Noise
Unit Size 085 100 115 125 145 150
Number of Compressors 222222
Nominal Size (1) (Tons) 40/40 50/50 60/60 70/70 85/70 85/85
Evaporator
Evaporator Model EG140 EG170 EG200 EG200 EG250 EG250
Water Storage (l) 269 223 204 204 415 415
Minimum Flow (l/s) 6 7.3 8.8 8.8 11.6 11.6
Maximum Flow l/s) 20.8 24.8 30.7 30.7 38 38
Water Connection Type Victaulic
(inch-mm) 6" - 168.3 6" - 168.3 6" - 168.3 6" - 168.3 6" - 168.3 6" - 168.3
Heat Recovery Heat-Exchanger
Type Brazed Plates
Water connection type Victaulic
PHR
Connection diameter 2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3
Water Storage capacity (l) 88991111
THR
Connection diameter (inch-mm) 2" - 60.3 2" - 60.3 2" - 60.3 2" - 60.3 3" O.D. - 76.1 3" O.D. - 76.1
Water Storage capacity (l) 10 10 14 14 16 16
Condenser
Number of Coils 222222
Fin series (Fins/ft) 192 192 192 192 192 192
Number of Rows 3/3 3/3 3/3 3/3 3/3 3/3
Condenser Fans
Quantity (1) 3/3 4/4 4/4 5/5 6/5 6/6
Diameter (mm) 762 762 762 762 762 762
Total Air Flow (m
3
/s) 21.0 24.1 27.2 30.1 34.7 36.2
Nominal Speed (rpm) 750 750 750 750 750 750
Motor kW (kW) 1.23 1.23 1.23 1.23 1.23 1.23
Min Starting/Oper Ambient (2)
PHR (°C) 000000
THR (°C) -18 -18 -18 -18 -18 -18
General Unit
Refrigerant HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a HFC 134a
222222
% Min. Load (3) 17 17 17 17 17 17
Weight. Capacities & Dimensions
PHR
Refrigerant Charge (1) (kg) 35/37 38/39 45/48 45/48 63/65 63/65
Oil Charge (1) (l) 6/6 7/7 10/10 10/10 11/11 11/11
Operating Weight (4) (kg) 3411 3541 4084 4179 5574 5629
Shipping Weight (4) (kg) 2655 2784 3325 3420 4812 4867
THR
Refrigerant Charge (1) (kg) 63 / 60 65 / 62 86 / 84 86 / 84 97 / 95 97 / 95
Oil Charge (1) (l) 5 / 4 5 / 4 8 / 7 8 / 7 8 / 7 8 / 7
Operating Weight (4) (kg) 3594 3724 4338 4433 5831 5886
Shipping Weight (4) (kg) 3308 3484 4113 4208 5387 5442
Dimensions
Length (mm) 4426 4426 5351 5351 6370 6370
Width (mm) 2260 2260 2260 2260 2260 2260
Height (mm) 2095 2095 2115 2115 2215 2215
(1) Data containing information on two circuits shown as follows: ckt1/ckt2
(2) Minimum start-up/operation ambient based on a 2.22 m/s wind across the condenser.
(3) Percent minimum load is for total machine at 10°C ambient and 7°C leaving chilled water temp. Not each individual circuit.
(4) With aluminum fins
RTAD-SVX01F-E4 21RTAD-SVX01F-E4 21
General Information
Water Connection
Diameter
No. Of independent
Refrigerant Circuits
