Trane RTAD 085 User Manual

44 RTAD-SVX01F-E4
Installation - Electrical
Table 26 - Unit Wiring 400/3/50 - Standard cooling unit / Partial Heat Recovery and Total Heat Recovery units
Unit Size
Standard
085 1 242 255 0.90 250 6 x 125 0.217
100 1 282 306 0.88 400 6 x 160 0.217
115 1 323 359 0.89 400 6 x 200 0.217
125 1 387 425 0.90 500 6 x 250 0.217
145 1 437 471 0.90 500 6 x 250 0.217
150 1 477 502 0.89 630 6 x 250 0.217
165 1 527 570 0.89 630 315 + 250 0.217
180 1 576 608 0.89 630 6 x 315 0.217
High Efficiency
085 1 242 255 0.90 250 6 x 125 0.217
100 1 291 315 0.88 400 6 x 160 0.217
115 1 332 368 0.89 400 6 x 200 0.217
125 1 405 443 0.90 500 6 x 250 0.217
145 1 446 480 0.90 500 6 x 250 0.217
150 1 486 511 0.89 630 6 x 250 0.217
High Ambient
085 1 242 255 0.90 400 6 x 160 0.217
100 1 291 315 0.88 400 6 x 200 0.217
115 1 332 368 0.89 400 6 x 250 0.217
125 1 405 443 0.90 500 6 x 250 0.217
145 1 446 480 0.90 630 6 x 250 0.217
150 1 486 511 0.89 630 6 x 315 0.217
165 1 527 570 0.89 630 400 + 315 0.217
180 1 576 608 0.89 800 6 x 400 0.217
Standard Low Noise
085 1 230 243 0.90 250 6 x 125 0.217
100 1 270 294 0.88 400 6 x 160 0.217
115 1 311 347 0.89 400 6 x 200 0.217
125 1 375 413 0.90 500 6 x 250 0.217
145 1 419 453 0.90 500 6 x 250 0.217
150 1 457 482 0.89 630 6 x 250 0.217
165 1 505 548 0.89 630 315 + 250 0.217
180 1 552 584 0.89 630 6 x 315 0.217
High Efficiency Low Noise
085 1 230 243 0.90 250 6 x 125 0.217
100 1 275 299 0.88 400 6 x 160 0.217
115 1 316 352 0.89 400 6 x 200 0.217
125 1 385 423 0.90 500 6 x 250 0.217
145 1 424 458 0.90 500 6 x 250 0.217
150 1 462 487 0.89 630 6 x 250 0.217
Standard Low Noise with Night Noise Set Back option
085 1 226 238 0.90 250 6 x 125 0.217
100 1 270 295 0.88 400 6 x 160 0.217
115 1 312 348 0.89 400 6 x 200 0.217
125 1 376 414 0.90 500 6 x 250 0.217
145 1 417 451 0.90 500 6 x 250 0.217
150 1 453 478 0.89 630 6 x 250 0.217
165 1 503 546 0.89 630 315 + 250 0.217
180 1 548 580 0.89 630 6 x 315 0.217
High Efficiency Low Noise with Night Noise Set Back option
085 1 231 244 0.90 250 6 x 125 0.217
100 1 270 295 0.88 400 6 x 160 0.217
115 1 317 353 0.89 400 6 x 200 0.217
125 1 381 419 0.90 500 6 x 250 0.217
145 1 381 456 0.90 500 6 x 250 0.217
150 1 381 483 0.89 630 6 x 250 0.217
Nbr of Power
Connections
Maximum
Amps (1)
Starting
Amps (2)
Power
Factor (5)
Disconnect
Switch Size (A)
Compressor
Fuse Size (A)
Evaporator
heater (kW)
