Trane RTAD 085 User Manual

Installation - Electrical
Table 27 - Unit Wiring 400/3/50/ cont - Standard cooling unit / Partial Heat Recovery and Total Heat Recovery units
Unit Size
Standard with High External Static Pressure
085 1 231 244 0.90 250 6 x 125 0.217
100 1 278 302 0.88 400 6 x 160 0.217
115 1 319 355 0.89 400 6 x 200 0.217
125 1 383 421 0.90 500 6 x 250 0.217
145 1 427 461 0.90 500 6 x 250 0.217
150 1 463 488 0.89 630 6 x 250 0.217
165 1 516 559 0.89 630 315 + 250 0.217
180 1 561 593 0.89 630 6 x 315 0.217
High Efficiency with High External Static Pressure
085 1 239 251 0.90 250 6 x 125 0.217
100 1 278 302 0.88 400 6 x 160 0.217
115 1 327 363 0.89 400 6 x 200 0.217
125 1 391 429 0.90 500 6 x 250 0.217
145 1 435 469 0.90 500 6 x 250 0.217
150 1 471 496 0.89 630 6 x 250 0.217
Table 28 - Motor Data 400/3/50 - Standard cooling unit / Partial Heat Recovery and Total Heat Recovery units
(400V)
Unit Size Qty Ckt 1 Ckt 2 Ckt 1 Ckt 2 Ckt 1 Ckt 2 Qty kW FLA size (A) VA A
Standard
085 2 80 80 106 106 144 144 6 2.05 4.5 3 x 50 1600 4
100 2 95 95 125 125 180 180 6 2.05 4.5 3 x 50 1600 4
115 2 111 111 146 146 217 2 17 6 2.05 4. 5 3 x 5 0 160 0 4
125 2 135 135 178 178 259 259 6 2.05 4.5 3 x 50 1600 4
145 2 162 135 214 178 291 259 9 2.05 4.5 3 x 63 1600 4
150 2 162 162 214 214 291 291 10 2.05 4.5 3 x 63 1600 4
165 2 196 162 259 214 354 291 11 2.05 4.5 3 x 63 1600 4
180 2 196 196 259 259 354 354 12 2.05 4.5 3 x 63 1600 4
High Efficiency
085 2 80 80 106 106 144 144 6 2.05 4.5 3 x 50 1600 4
100 2 95 95 125 125 180 180 8 2.05 4.5 3 x 50 1600 4
115 2 111 111 146 146 217 2 17 8 2.05 4. 5 3 x 5 0 160 0 4
125 2 135 135 178 178 259 259 10 2.05 4.5 3 x 50 1600 4
145 2 162 135 214 178 291 259 11 2.05 4.5 3 x 63 1600 4
150 2 162 162 214 214 291 291 12 2.05 4.5 3 x 63 1600 4
Standard Low Noise
085 2 80 80 106 106 144 144 6 1.30 2.5 3 x 50 1600 4
100 2 95 95 125 125 180 180 6 1.30 2.5 3 x 50 1600 4
115 2 111 111 146 146 217 2 17 6 1.3 0 2. 5 3 x 50 160 0 4
125 2 135 135 178 178 259 259 6 1.30 2.5 3 x 50 1600 4
145 2 162 135 214 178 291 259 9 1.30 2.5 3 x 63 1600 4
150 2 162 162 214 214 291 291 10 1.30 2.5 3 x 63 1600 4
165 2 196 162 259 214 354 291 11 1.30 2.5 3 x 63 1600 4
180 2 196 196 259 259 354 354 12 1.30 2.5 3 x 63 1600 4
High Efficiency Low Noise option
085 2 80 80 106 106 144 144 6 1.30 2.5 3 x 50 1600 4
100 2 95 95 125 125 180 180 8 1.30 2.5 3 x 50 1600 4
115 2 111 111 146 146 217 2 17 8 1.3 0 2. 5 3 x 50 160 0 4
125 2 135 135 178 178 259 259 10 1.30 2.5 3 x 50 1600 4
145 2 162 135 214 178 291 259 11 1.30 2.5 3 x 63 1600 4
150 2 162 162 214 214 291 291 12 1.30 2.5 3 x 63 1600 4
Standard Low Noise with Night Noise Set Back option
085 2 80 80 106 106 144 144 4 1.05 2.6 3 x 50 1600 4
100 2 95 95 125 125 180 180 6 1.05 2.6 3 x 50 1600 4
115 2 111 111 146 146 217 2 17 6 1.0 5 2. 6 3 x 50 160 0 4
125 2 135 135 178 178 259 259 6 1.05 2.6 3 x 50 1600 4
145 2 162 135 214 178 291 259 8 1.05 2.6 3 x 63 1600 4
150 2 162 162 214 214 291 291 8 1.05 2.6 3 x 63 1600 4
165 2 196 162 259 214 354 291 10 1.05 2.6 3 x 63 1600 4
180 2 196 196 259 259 354 354 10 1.05 2.6 3 x 63 1600 4
Nbr of Power
Connections
Maximum
Amps (1)
Starting
Amps (2)
Power
Factor (5)
Disconnect
Switch Size (A)
Compressor
Fuse Size (A)
Evaporator
heater (kW)
RLA Amps Max Amps (3) Starting Amps (4) Fans fuse
Compressor (Each) Fans (Each) Control
RTAD-SVX01F-E4 45
