46 RTAD-SVX01F-E4
Installation - Electrical
Table 29 - Motor Data 400/3/50/ cont - Standard cooling unit / Partial Heat Recovery and Total Heat Recovery units
Unit Size Qty Ckt 1 Ckt 2 Ckt 1 Ckt 2 Ckt 1 Ckt 2 Qty kW FLA size (A) VA (400V)
High Efficiency Low Noise with Night Noise Set Back option
085 2 80 80 106 106 144 144 6 1.05 2.6 3 x 50 1600 4
100 2 95 95 125 125 180 180 6 1.05 2.6 3 x 50 1600 4
115 2 111 111 146 146 217 2 17 8 1.0 5 2. 6 3 x 50 160 0 4
125 2 135 135 178 178 259 259 8 1.05 2.6 3 x 50 1600 4
145 2 162 135 214 178 291 259 10 1.05 2.6 3 x 63 1600 4
150 2 162 162 214 214 291 291 10 1.05 2.6 3 x 63 1600 4
Standard with High External Static Pressure
085 2 80 80 106 106 144 144 4 2.21 3.9 3 x 50 1600 4
100 2 95 95 125 125 180 180 6 2.21 3.9 3 x 50 1600 4
115 2 111 111 146 146 217 2 17 6 2.21 3. 9 3 x 5 0 160 0 4
125 2 135 135 178 178 259 259 6 2.21 3.9 3 x 50 1600 4
145 2 162 135 214 178 291 259 8 2.21 3.9 3 x 63 1600 4
150 2 162 162 214 214 291 291 8 2.21 3.9 3 x 63 1600 4
165 2 196 162 259 214 354 291 10 2.21 3.9 3 x 63 1600 4
180 2 196 196 259 259 354 354 10 2.21 3.9 3 x 63 1600 4
High Efficiency with High External Static Pressure
085 2 80 80 106 106 144 144 6 2.21 3.9 3 x 50 1600 4
100 2 95 95 125 125 180 180 6 2.21 3.9 3 x 50 1600 4
115 2 111 111 146 146 217 2 17 8 2.21 3. 9 3 x 5 0 160 0 4
125 2 135 135 178 178 259 259 8 2.21 3.9 3 x 50 1600 4
145 2 162 135 214 178 291 259 10 2.21 3.9 3 x 63 1600 4
150 2 162 162 214 214 291 291 10 2.21 3.9 3 x 63 1600 4
Notes:
1. Maximum Compressors FLA + all fans FLA + control Amps
2. Starting Amps of the circuit with the largest compressor circuit including fans plus RLA of the second circuit including fans + control Amps
3. Maximum FLA per compressor.
4. Compressors starting Amps, Star delta start.
5. Compressor Power Factor
Table 30 - Compressor motor electrical data - 50 Hz - Free Cooling unit
Unit Size
RTAD 085 FC STD 400/3/50 149 239 251 0.90
RTAD 085 FC STD 400/3/50 149 239 251 0.90
RTAD 100 FC STD 400/3/50 169 278 302 0.88
RTAD 115 FC STD 400/3/50 199 319 355 0.89
RTAD 125 FC STD 400/3/50 244 391 429 0.90
RTAD 145 FC STD 400/3/50 268 431 465 0.90
RTAD 150 FC STD 400/3/50 291 471 496 0.89
RTAD 165 FC STD 400/3/50 294 520 563 0.89
RTAD 180 FC STD 400/3/50 352 569 601 0.89
RTAD 085 FC HE 400/3/50 149 239 251 0.90
RTAD 100 FC HE 400/3/50 174 286 310 0.88
RTAD 115 FC HE 400/3/50 204 327 363 0.89
RTAD 125 FC HE 400/3/50 249 399 437 0.90
RTAD 145 FC HE 400/3/50 273 439 473 0.90
RTAD 150 FC HE 400/3/50 296 479 504 0.89
(1) To take in account for the sizing of power cables
RLA Amps Max Amps (3) Starting Amps (4) Fans fuse
Compressor (Each) Fans (Each) Control
Nominal voltage
(V/Ph/Hz)
Maximum unit kW
(kW)
Maximum RLA (1)
(A)
Starting amps
(A)
Power factor
