Setpoint values are increased by pressing the Plus (+) key and
decreased by pressing the Minus (-) key. Once a setpoint is changed,
press the Enter key to accept the new setting. If the Cancel key is
pressed, the setpoint value on the display will be ignored and the origi-
nal setpoint will remain. The display will not advance until either Enter
or Cancel is pressed.
13-3 d. Passwords
Passwords are needed to enter into the Service Setup Menu and the
Machine Configuration Menu. Both of these menus are accessed
through the Service Settings key. If access into these menus is neces-
sary, follow the list of steps below:
1. Press Service Settings
2. Press Next until the readout in the display is:
3. To enter into the Field Start-up Group, press:
+ + - - + + Enter
4. To enter into the Machine Configuration Group,
press:
+ - + - + - Enter
Refer to the IOM for the list of items found in Start-up Group and
Machine Configuration Group.
13-3 e. Select Report Group and Select Settings Group
Flowcharts
Refer to the IOM for the display readouts found under each menu. The
first block of the flowchart is the header which is shown on the display
after the menu key is pressed. For example:
Press Chiller Report and the readout on the display will be
PASSWORD REQUIRED FOR FURTHER ACCESS
PLEASE ENTER PASSWORD
To Next Page
