Figure 2. RuptureGuard shipping crate
Unpacking
NNOOTTIICCEE
RRuuppttuurree DDiisskk DDaammaaggee!!
FFaaiilluurree ttoo ffoollllooww iinnssttrruuccttiioonnss bbeellooww ccoouulldd rreessuulltt iinn
rruuppttuurree ddiisskk ddaammaaggee..
TThhee rreevveerrssee bbuucckklliinngg ddiisskk ccaasssseettttee ccoommeess iinnssttaalllleedd
iinn tthhee rreelliieeff vvaallvvee bbooddyy.. TThhiiss iiss aa ffrraaggiillee,, pprreecciissiioonn
ddeevviiccee.. EExxttrreemmee ccaarree mmuusstt bbee ttaakkeenn wwhheenn
uunnppaacckkiinngg,, hhaannddlliinngg aanndd iinnssttaalllliinngg tthhee
RRuuppttuurreeGGuuaarrdd aasssseemmbbllyy.. IIff aannyy ddaammaaggee iiss vviissiibbllee,,
tthhee ddiisskk MMUUSSTT bbee rreeppllaacceedd..
Unpack the carton containing the RuptureGuard™
valve/disk assembly and optional inlet and outlet
adapter flanges.
IImmppoorrttaanntt:: The surface of the rupture disk is extremely
fragile and the domed portion of the disk
should never be touched! Any dent,
dimple, or imperfection is an indication that
the disk is damaged and should be
replaced.
Figure 3. Three-inch (76.2 mm) RuptureGuard valve
assembly (partially unpacked)
Figure 4. Four-inch (101.6 mm) RuptureGuard valve
assembly with spool piece (partially unpacked)
Figure 5. Four-inch (101.6 mm) RuptureGuard valve
assembly (without spool piece) (partially unpacked)
NNoottee:: Four-inch (101.6 mm) RuptureGuard
™
valve
assembly (without spool piece) is used ONLY
with 250E Heat Recovery CenTraVac
™
chillers;
some models may require additional parts (i.e.,
thread-reducing flange, stud, and nut).
Compare the parts received to the following packing
lists and ensure that all parts have been received. If any
parts are missing, contact the supplier using telephone
number provided on the packing list.
GGeenneerraall IInnffoorrmmaattiioonn
